QNAP TS-464EU-8G SAN/NAS Storage System - Intel Celeron N5095 Quad-core (4 Core) 2 GHz - 4 x HDD Supported - 0 x HDD Installed - 4 x SSD Supported - 0 x SSD Installed - 8 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, JBOD - 4 x Total Bays - 4 x 2.5"/3.5" Bay - 2.5 Gigabit Ethernet - HDMI - 4 USB Port(s) - 2 USB 2.0 Port(s) - Network (RJ-45) - QTS 5.0.1 - LDAP, HTTPS, L2TP, SFTP, DHCP, SSH, IPSec, FTPS, AFP, FTP, CIFS/SMB, ... - 4 GB Flash Memory Capacity - 1
Intel Celeron N5095 Quad-core (4 Core) 2 GHz - 4 x HDD Supported - 0 x HDD Installed - 4 x SSD Supported - 0 x SSD Installed - 8 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, JBOD - 4 x Total Bays - 4 x 2.5"/3.5" Bay - 2.5 Gigabit Ethernet - HDMI - 4 USB Port(s) - 2 USB 2.0 Port(s) - Network (RJ-45) - QTS 5.0.1 - LDAP, HTTPS, L2TP, SFTP, DHCP, SSH, IPSec, FTPS, AFP, FTP, CIFS/SMB, ... - 4 GB Flash Memory Capacity - 1U - Rack-mountable
| Maximum Power Supply Wattage | 100 W |
| Number of Hard Drives Installed | 0 |
| Processor Core | Quad-core (4 Core) |
| Additional Warranty Information | The TS-464eU is backed by a 3-year warranty at no additional cost. |
| Brand Name | QNAP |
| Controller Type | Serial ATA/600 |
| Depth | 12.7" |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Flash Memory Capacity | 4 GB |
| Form factor | Rack-mountable |
| Height | 1.7" |
| Limited Warranty | 3 Year |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TS-464EU-8G-US |
| Manufacturer Website Address | http://www.qnap.com |
| Marketing Information | The TS-464eU is powered by Intel® Celeron® N5095 quad-core processor (burst up to 2.9 GHz). The space-efficient short depth design makes it easy to install in small media cabinets or places with a lot of cabling. With expandable storage capacity and feature-rich apps the TS-464eU surpasses the previous generation. - 2.5GbE connectivity
Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports. - HDMI Output
Supports 4K media playback and real-time transcoding. - NVMe SSD application
Two M.2 PCIe NVMe SSD slots support Qtier™ auto-tiering technology and SSD caching. - USB interface
Two USB 3.2 Gen 2 10Gbps ports for faster data transfer. - Backup and data recovery
Protects PC/Macs virtual machines software containers cloud data and SaaS services. - Hybrid cloud applications
Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS. Quad-core Processor burst up to 2.9 GHz The TS-464eU is powered by Intel® Celeron® N5095 quad-core processor (burst up to 2.9 GHz) with 8 GB DDR4 memory. With Intel® AES-NI encryption engine the TS-x64eU provides unmatched encryption performance with AES-256 bit encryption acceleration boosting system performance while ensuring the safety of sensitive business data stored in the NAS. Build a High-Speed 2.5GbE Network Environment QNAP offers comprehensive budget-friendly storage and networking solutions that provide an array of connectivity possibilities. Easily and flexibly upgrade your workplace or home network now to handle bandwidth-hungry applications. - A fast 2.5GbE NAS
A QNAP NAS featuring one or more 2.5GbE ports and Port Trunking allows you to combine multiple ports for greater bandwidth potential. - Upgrade computers and servers
Servers and desktops can install PCIe-based QNAP network cards that support 10G/5G/2.5G/1G/100M Multi-Gig. - Add a 5GbE port to laptops
Laptops and upgrade-limited computers can use QNAP's portable USB 3.2 Gen 1 to 5GbE adapter that allows you to connect to 5G/2.5G/1G/100M networks via USB. - A switch that supports 2.5GbE+
QNAP's 10GbE/NBASE-T switches support 10G/5G/2.5G/1G/100M and allow connecting multiple workstations and devices for high-speed collaboration in device-dense environments. |
| Memory Technology | DDR4 SDRAM |
| Number of Network (RJ-45) Ports | 2 |
| Number of Total Expansion Bays | 4 |
| Operating System | QTS 5.0.1 |
| Package Contents | - TS-464EU-8G SAN/NAS Storage System
- 1 x Ethernet Cable
- 1 x Power Cord
- 16 x Flat Head Screws (for 3.5" HDD)
- 12 x Flat Head Screws (for 2.5" HDD)
- Quick Installation Guide (QIG)
- 2 x Hangers
- 2 x Holders
|
| Processor Manufacturer | Intel |
| Processor model | N5095 |
| Processor Speed | 2 GHz |
| Processor Type | Celeron |
| Product Model | TS-464EU-8G |
| Product Name | TS-464EU-8G SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| Protocols | AFP |
| Protocols | FXP |
| Protocols | TLS |
| Protocols | TFTP |
| Protocols | Telnet |
| Protocols | HTTP |
| Protocols | iSCSI |
| Protocols | L2TP |
| Protocols | DDNS |
| Protocols | CIFS/SMB |
| Protocols | FTPS |
| Protocols | FTP |
| Protocols | SSL |
| Protocols | SNMPv2 |
| Protocols | IPv6 |
| Protocols | PPTP |
| Protocols | NFS |
| Protocols | IPSec |
| Protocols | SFTP |
| Protocols | DHCP |
| Protocols | HTTPS |
| Protocols | IPv4 |
| Protocols | WEBDAV |
| Protocols | SSH |
| Protocols | LDAP |
| Rack Height | 1U |
| RAID Levels | 0 1 5 6 10 JBOD |
| RAID Supported | Yes |
| Standard Memory | 8 GB |
| UPC Alternates | 885022024384 |
| Weight (Approximate) | 9.59 lb |
| Width | 19" |
