QNAP TS-873AEU-RP-4G SAN/NAS Storage System - AMD Ryzen V1500B Quad-core (4 Core) 2.20 GHz - 8 x HDD Supported - 0 x HDD Installed - 8 x SSD Supported - 0 x SSD Installed - 4 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, JBOD - 8 x Total Bays - 8 x 2.5"/3.5" Bay - 1 x Total Slot(s) - 2.5 Gigabit Ethernet - 4 USB Port(s) - Network (RJ-45) - QuTS hero h5.0.0 - LDAP, HTTPS, L2TP, SFTP, DHCP, SSH, IPSec, FTPS, AFP, CIFS/SMB, FTP, ... - 5 GB Flash Memory
AMD Ryzen V1500B Quad-core (4 Core) 2.20 GHz - 8 x HDD Supported - 0 x HDD Installed - 8 x SSD Supported - 0 x SSD Installed - 4 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, JBOD - 8 x Total Bays - 8 x 2.5"/3.5" Bay - 1 x Total Slot(s) - 2.5 Gigabit Ethernet - 4 USB Port(s) - Network (RJ-45) - QuTS hero h5.0.0 - LDAP, HTTPS, L2TP, SFTP, DHCP, SSH, IPSec, FTPS, AFP, CIFS/SMB, FTP, ... - 5 GB Flash Memory Capacity - 2U - Rack-mountable
| Maximum Power Supply Wattage | 300 W |
| Number of Hard Drives Installed | 0 |
| Number of Power Supplies Installed | 2 |
| Number of Total Expansion Slots | 1 |
| Processor Core | Quad-core (4 Core) |
| Redundant Power Supply | Yes |
| Brand Name | QNAP |
| Controller Type | Serial ATA/600 |
| Depth | 11.7" |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Expansion Slot Type | PCI Express 3.0 x8 |
| Flash Memory Capacity | 5 GB |
| Form factor | Rack-mountable |
| Height | 3.5" |
| Limited Warranty | 3 Year |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TS-873AEU-RP-4G-US |
| Manufacturer Website Address | http://www.qnap.com |
| Marketing Information | Short Depth Rackmount dual-2.5GbE NAS. Powered by a Quad-core AMD Ryzen™ processor supporting 10/25GbE or M.2 SSD caching PCIe expandability for virtual applications
(Supports QTS or QuTS hero operating systems)
The compact 2U rackmount TS-873AeU-RP combines an AMD Ryzen™ V1000 series V1500B quad-core/eight-thread 2.2 GHz processor and dual-2.5GbE connectivity in one chassis. Compared to its previous generation the TS-873AeU-RP is enhanced with two M.2 PCIe Gen3 x 1 ports for NVMe SSD cache acceleration or Edge TPU empowered AI image recognition. Cutting-edge hardware integrated with comprehensive software solutions makes the TS-873AeU-RP the preeminent choice to tackle resource-demanding applications and tasks such as virtual machines or intensive multi-user access. The space-efficient short depth design of only 11.7 inches (297.4 mm) makes it easy to install in small media cabinets or places with a lot of cabling. The TS-873AeU-RP also features two redundant power supplies to ensure maximum system uptime. - Dual-2.5GbE connectivity
Features two 2.5GbE ports. Up to 5 Gbps transfer speeds can be achieved by using port trunking. - PCIe expandability
Features one PCIe Gen3 x 8 port. Add extra functionality with PCIe cards including 10/25GbE ports QM2 or Fibre Channel. - Optimized SSD performance
Features two M.2 PCIe Gen3 ports to install NVMe SSDs and empower Qtier™ and SSD caching technology. - Hybrid cloud storage
Supports block-based and file-based cloud storage gateways with local caching for low-latency access to cloud data. - Virtual machine applications
Host multiple virtual machines and containers to run a wide range of applications. - 2U Short depth design
The rackmount NAS has a short-depth design of only 30 cm. It is perfectly suited for installation in a compact rack or places with a lot of cabling. 2U Short depth design for up to 38% reduction in size The 2U rackmount TS-873AeU-RP has a short depth design of only 11.7 inches (297.4 mm) making it an excellent choice for smaller racks wall-mount AV rack cabinets and network rack cabinets. The space saved by the short depth design can be reserved for cabling or ventilation. The TS-873AeU-RP is space-saving for flexible deployment and is especially suitable for multiple locations and applications including offices audiovisual rooms and security surveillance recording. |
| Memory Technology | DDR4 SDRAM |
| Number of Total Expansion Bays | 8 |
| Operating System | QuTS hero h5.0.0 |
| Package Contents | - TS-873AEU-RP-4G SAN/NAS Storage System
- 1 x Ethernet Cable
- 2 x Power Cords
- 32 x Flat Head Screw (for 3.5" HDD)
- 24 x Flat Head Screw (for 2.5" HDD)
- Quick Installation Guide (QIG)
|
| Processor Manufacturer | AMD |
| Processor model | V1500B |
| Processor Speed | 2.20 GHz |
| Processor Type | Ryzen |
| Product Model | TS-873AEU-RP-4G |
| Product Name | TS-873AEU-RP-4G SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| Protocols | TFTP |
| Protocols | FXP |
| Protocols | TLS |
| Protocols | iSCSI |
| Protocols | Telnet |
| Protocols | IPSec |
| Protocols | HTTP |
| Protocols | FTPS |
| Protocols | SSL |
| Protocols | HTTPS |
| Protocols | FTP |
| Protocols | DHCP |
| Protocols | SNMPv2 |
| Protocols | PPTP |
| Protocols | NFS |
| Protocols | CIFS/SMB |
| Protocols | AFP |
| Protocols | IPv6 |
| Protocols | IPv4 |
| Protocols | SFTP |
| Protocols | LDAP |
| Protocols | DDNS |
| Protocols | L2TP |
| Protocols | WEBDAV |
| Protocols | SSH |
| Rack Height | 2U |
| RAID Levels | 0 1 5 6 10 50 60 JBOD |
| Standard Memory | 4 GB |
| Total Number of USB Ports | 4 |
| UPC Alternates | 885022023431 |
| Weight (Approximate) | 17.97 lb |
| Width | 19" |
