Cisco Barebone System - 2U Rack-mountable - Socket R LGA-2011 - 2 x Processor Support - Intel C600 Chip - 384 GB DDR3 SDRAM DDR3-1600/PC3-12800 Maximum RAM Support - 24 Total Memory Slots - Serial ATA RAID Supported, Serial Attached SCSI (SAS) Controller - 12 3.5" Bay(s) - Network (RJ-45) - Processor Support (Xeon) - 3 Year
Intel C600 Chip - 384 GB DDR3 SDRAM DDR3-1600/PC3-12800 Maximum RAM Support - 24 Total Memory Slots - Serial ATA RAID Supported, Serial Attached SCSI (SAS) Controller - 12 3.5" Bay(s) - Network (RJ-45) - Processor Support (Xeon) - 3 Year
| 64-bit Processing | Yes |
| Chipset | Intel C600 |
| Chipset Manufacturer | Intel |
| Chipset Model | C600 |
| Maximum Memory Supported | 384 GB |
| Memory Standard | DDR3-1600/PC3-12800 |
| Number of PCI Express x8 Slots | 3 |
| Number of Processors Supported | 2 |
| Number of SAS Interfaces | 12 |
| Number of Total Expansion Slots | 5 |
| Processor Socket | Socket R LGA-2011 |
| Processor Supported | Xeon |
| Processor Technology | Virtualization Technology |
| Processor Technology | Enhanced SpeedStep Technology |
| Processor Technology | vPro Technology |
| Processor Technology | Hyper-Threading Technology |
| Processor Technology | Trusted Execution Technology |
| QuickPath Interconnect | 8 GT/s |
| Brand Name | Cisco |
| Certifications & Standards | Safety: - UL 60950-1 No. 21CFR1040 Second Edition
- CAN/CSA-C22.2 No. 60950-1 Second Edition
- IEC 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- AS/NZS 60950-1
- GB4943 2001
EMC: Emissions: - 47CFR Part 15 (CFR 47) Class A
- AS/NZS CISPR22 Class A
- CISPR2 2 Class A
- EN55022 Class A
- ICES003 Class A
- VCCI Class A
- EN61000-3-2
- EN61000-3-3
- KN22 Class A
- CNS13438 Class A
EMC: Immunity: - EN55024
- CISPR24
- EN300386
- KN24
|
| Controller Type | Serial ATA |
| Controller Type | Serial Attached SCSI (SAS) |
| Depth | 29.3" |
| Ethernet Technology | Gigabit Ethernet |
| Form factor | Rack-mountable |
| Height | 3.4" |
| Input voltage | 110 V AC |
| Input voltage | 220 V AC |
| Limited Warranty | 3 Year |
| Manufacturer | Cisco Systems Inc |
| Manufacturer Part Number | UCSC-C240-M3L |
| Manufacturer Website Address | http://www.cisco.com |
| Marketing Information | High Performance and Internal Storage The Cisco UCS C240 M3 Rack Server is designed for both performance and expandability over a wide range of storage-intensive infrastructure workloads ranging from big data to collaboration. |
| Memory Technology | DDR3 SDRAM |
| Number of Total Memory Slots | 24 |
| Package Contents | - UCS C240 M3 Barebone System
- Rail Kit
|
| Product Name | UCS C240 M3 Barebone System |
| Product Series | C240 M3 |
| Product Type | Barebone System |
| Rack Height | 2U |
| UPC Alternates | 882658472343 |
| Width | 17.5" |
