CyberPower CPS1220RM 120 - 120 VAC 20A Basic PDU - 12 Outlets, 15 ft, NEMA 5-20P, Horizontal, 1U, 3YR Warranty
12 Outlets, 15 ft, NEMA 5-20P, Horizontal, 1U, 3YR Warranty
| Number of Cord/Cable | 1 |
| PDU Type | Basic |
| Phase | Single Phase |
| Power Rating (VA) | 1800 VA |
| Receptacle Detail | 12 x NEMA 5-20R |
| Additional Information | - Circuit Breaker | 20 A
- Plug Style | Straight
- Switch | Lighted On/Off
- Outlets - Front | 6
- Outlets - Rear | 6
- Overload Protection | 20A
- Clamping Voltage | 800V (H-N)
- Clamping Voltage | 800V (H-N)
- Material of Construction | Metal
- Operating Elevation | 0 - 10000 ft (0 - 3048 m)
- Operating Relative Humidity | 0 - 95 % (non-condensing)
- Operating Temperature | 32 - 104 °F (0 - 40 °C)
- Storage Elevation | 0 - 50000 ft (0 - 15239 m)
- Storage Temperature | 5 - 113 °F (-15 - 45 °C)
|
| Additional Warranty Information | CyberPower stands behind its products with an industry-leading 3 year warranty. CyberPower also offers a #1 rated technical support team that will assist you with product installation or warranty concerns --- Free of Charge. |
| Brand Name | CyberPower |
| Certifications & Standards | - UL Recognized
- UL 498A
- UL1449 4th Edition
- cUL
|
| Circuit Breaker | Yes |
| Cord Length | 15 ft |
| Country of origin | China |
| Depth | 4.8" |
| Environmental Certification | RoHS |
| Height | 1.8" |
| Input current | 20 A |
| Input voltage | 120 V AC |
| Input Voltage Range | 100 V AC - 125 V AC |
| Limited Warranty | 3 Year |
| Manufacturer | CyberPower Systems Inc |
| Manufacturer Part Number | CPS-1220RM |
| Manufacturer Website Address | http://www.cyberpowersystems.com |
| Marketing Information | The CyberPower CPS1220RM a 12-outlet (6 front 6 rear) rackmount power distribution unit (PDU) provides 100 - 125 V 20A output. It distributes power to 10 NEMA 5-20R receptacles from a single NEMA 5-20P input with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications the CPS1220RM has durable metal housing and a 15-foot AC power cord. It can be mounted either horizontally or vertically includes a cord retention tray and is ETL/RoHS certified. A three-year warranty covers the CPS1220RM for three years for as long as you own the product. More from the Manufacturer |
| Mount Type | Rack-mountable |
| Package Contents | - CPS-1220RM Unit
- Warranty Card/Manual
|
| Parts Warranty/Labor | 3 Year Parts & Labor |
| Plug/Connector Type | NEMA 5-20P |
| Product color | Black |
| Product Name | Rackmount CPS-1220RM 20A PDU |
| Product Type | PDU |
| Protection Type | Short Circuit Protection |
| Rack Height | 1U |
| Receptacle Type | NEMA 5-20R |
| UPC Alternates | 649532893522 701490572984 818242584345 |
| Weight (Approximate) | 6 lb |
| Width | 17.3" |
