Lenovo ThinkSystem DE2000H DAS/SAN Storage System - 12 x HDD Supported - 0 x HDD Installed - 12 x SSD Supported - 0 x SSD Installed - 2 x 12Gb/s SAS Controller - RAID Supported 0, 1, 3, 5, 6, 10 - 12 x Total Bays - 12 x 3.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - FCP, SSH, SMI-S, SNMP, SSL, LDAP - 4 SAS Port(s) External - 2U - Rack-mountable
12 x HDD Supported - 0 x HDD Installed - 12 x SSD Supported - 0 x SSD Installed - 2 x 12Gb/s SAS Controller - RAID Supported 0, 1, 3, 5, 6, 10 - 12 x Total Bays - 12 x 3.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - FCP, SSH, SMI-S, SNMP, SSL, LDAP - 4 SAS Port(s) External - 2U - Rack-mountable
| Fibre Channel | Yes |
| Fibre Channel | Yes |
| Fibre Channel | Yes |
| Maximum Power Supply Wattage | 913 W |
| Maximum Power Supply Wattage | 913 W |
| Maximum Power Supply Wattage | 913 W |
| Number of Controllers | 2 |
| Number of Controllers | 2 |
| Number of Controllers | 2 |
| Number of Hard Drives Installed | 0 |
| Number of Hard Drives Installed | 0 |
| Number of Hard Drives Installed | 0 |
| Number of SAS Ports (External) | 4 |
| Number of SAS Ports (External) | 4 |
| Number of SAS Ports (External) | 4 |
| SSD Cache Capacity | 8 GB |
| SSD Cache Capacity | 8 GB |
| SSD Cache Capacity | 8 GB |
| Brand Name | Lenovo |
| Brand Name | Lenovo |
| Brand Name | Lenovo |
| Depth | 19" |
| Depth | 19" |
| Depth | 19" |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Form factor | Rack-mountable |
| Form factor | Rack-mountable |
| Form factor | Rack-mountable |
| Height | 3.3" |
| Height | 3.3" |
| Height | 3.3" |
| Host interface | 12Gb/s SAS |
| Host interface | 12Gb/s SAS |
| Host interface | 12Gb/s SAS |
| Manufacturer | Lenovo Group Limited |
| Manufacturer | Lenovo Group Limited |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7Y70A00YWW |
| Manufacturer Part Number | 7Y70A00YWW |
| Manufacturer Part Number | 7Y70A00YWW |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Marketing Information | Lenovo ThinkSystem DE2000H is a low-cost hybrid entry-level storage system that is designed to provide performance simplicity capacity security and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options flexible drive configurations and enhanced data management features. This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array its key features and specifications components and options and configuration guidelines. This guide is intended for technical specialists sales specialists sales engineers and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions. |
| Marketing Information | Lenovo ThinkSystem DE2000H is a low-cost hybrid entry-level storage system that is designed to provide performance simplicity capacity security and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options flexible drive configurations and enhanced data management features. This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array its key features and specifications components and options and configuration guidelines. This guide is intended for technical specialists sales specialists sales engineers and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions. |
| Marketing Information | Lenovo ThinkSystem DE2000H is a low-cost hybrid entry-level storage system that is designed to provide performance simplicity capacity security and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options flexible drive configurations and enhanced data management features. This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array its key features and specifications components and options and configuration guidelines. This guide is intended for technical specialists sales specialists sales engineers and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions. |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of Total Expansion Bays | 12 |
| Number of Total Expansion Bays | 12 |
| Number of Total Expansion Bays | 12 |
| Plug/Connector Type | C14 |
| Plug/Connector Type | C14 |
| Plug/Connector Type | C14 |
| Product Family | ThinkSystem DE |
| Product Family | ThinkSystem DE |
| Product Family | ThinkSystem DE |
| Product Line | ThinkSystem |
| Product Line | ThinkSystem |
| Product Line | ThinkSystem |
| Product Model | DE2000H |
| Product Model | DE2000H |
| Product Model | DE2000H |
| Product Name | ThinkSystem DE2000H DAS/SAN Storage System |
| Product Name | ThinkSystem DE2000H DAS/SAN Storage System |
| Product Name | ThinkSystem DE2000H DAS/SAN Storage System |
| Product Series | DE |
| Product Series | DE |
| Product Series | DE |
| Product Type | DAS/SAN Storage System |
| Product Type | DAS/SAN Storage System |
| Product Type | DAS/SAN Storage System |
| Protocols | SSL |
| Protocols | FCP |
| Protocols | LDAP |
| Protocols | SNMP |
| Protocols | FCP |
| Protocols | SSH |
| Protocols | SSH |
| Protocols | FCP |
| Protocols | LDAP |
| Protocols | SNMP |
| Protocols | SSH |
| Protocols | SMI-S |
| Protocols | SSL |
| Protocols | LDAP |
| Protocols | SNMP |
| Protocols | SMI-S |
| Protocols | SSL |
| Protocols | SMI-S |
| Rack Height | 2U |
| Rack Height | 2U |
| Rack Height | 2U |
| RAID Levels | 0 1 3 5 6 10 |
| RAID Levels | 0 1 3 5 6 10 |
| RAID Levels | 0 1 3 5 6 10 |
