QNAP TVS-872X-I3-8G SAN/NAS Storage System - Intel Core i3 i3-8100T Quad-core (4 Core) 3.10 GHz - 8 x HDD Supported - 0 x HDD Installed - 8 x SSD Supported - 0 x SSD Installed - 8 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD - 8 x Total Bays - 8 x 2.5"/3.5" Bay - 2 x Total Slot(s) - 10 Gigabit Ethernet, Gigabit Ethernet - HDMI - 5 USB Port(s) - Network (RJ-45) - QTS 4.5.1 - TCP/IP, HTTPS, SMTP, LDAP, L2TP, SFTP, DHCP, SSH, SMSC, IPSe
Intel Core i3 i3-8100T Quad-core (4 Core) 3.10 GHz - 8 x HDD Supported - 0 x HDD Installed - 8 x SSD Supported - 0 x SSD Installed - 8 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD - 8 x Total Bays - 8 x 2.5"/3.5" Bay - 2 x Total Slot(s) - 10 Gigabit Ethernet, Gigabit Ethernet - HDMI - 5 USB Port(s) - Network (RJ-45) - QTS 4.5.1 - TCP/IP, HTTPS, SMTP, LDAP, L2TP, SFTP, DHCP, SSH, SMSC, IPSec, FTPS, ... - 5 GB - Tower
| Maximum Power Supply Wattage | 250 W |
| Number of Hard Drives Installed | 0 |
| Number of Power Supplies Installed | 1 |
| Number of Total Expansion Slots | 2 |
| Processor Core | Quad-core (4 Core) |
| Brand Name | QNAP |
| Controller Type | Serial ATA/600 |
| Country of origin | Taiwan |
| Depth | 11" |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Expansion Slot Type | PCI Express 3.0 x4 |
| Expansion Slot Type | PCI Express 3.0 x16 |
| Flash Memory Capacity | 5 GB |
| Form factor | Tower |
| Height | 7.4" |
| Limited Warranty | 2 Year |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TVS-872X-I3-8G-US |
| Manufacturer Website Address | http://www.qnap.com |
| Marketing Information | High-performance multifunctional 10GbE NAS featuring M.2 NVMe SSD caching and 4K HDMI output for virtualization and multimedia Powered by an Intel® Core™ i3 processor the high-performance TVS-872X NAS features built-in 10GbE connectivity for boosted virtualization performance and streamlined backup and application workflows from multiple workstations. The TVS-872X also supports M.2 NVMe SSDs for cache acceleration PCIe expansion multi-cloud backup 4K HDMI 2.0 output and real-time transcoding alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient reliable and multifunctional NAS solution. -
5-speed 10GBASE-T RJ45 connectivity accelerates virtualization intensive file access large backup/restoration tasks and media transfer. -
Dual M.2 PCIe Gen 3 x2 NVMe SSD slots enable cache acceleration or SSD storage pools for improved performance. -
PCIe expansion allows for 2.5/5/10/25GbE network cards QM2 card QXP storage expansion cards or graphics cards. -
4K media playback and real-time transcoding; display multimedia content saved on the NAS via HDMI 2.0 (4K @60Hz) output. -
Host multiple virtual machines and containers to run a wide range of applications and services. -
A business-class backup center supporting backup/restore of cloud data and VMs (including Google™ Workspace Microsoft 365® VMware® and Hyper-V). Quad-core 3.1 GHz processor with up to 64 GB memory The TVS-872X adopts an Intel® Core™ i3-8100T quad-core 3.1 GHz processor with dual-channel DDR4 memory (expandable to 64 GB) to tackle heavy multitasking workloads. AES-NI encryption support boosts encryption performance to secure NAS data without impacting overall system operations. Build a budget-friendly 10GbE environment The TVS-872X has two Gigabit ports and one 10GBASE-T Multi-Gig (10G/5G/2.5G/1G/100M) port for high-speed networking to satisfy bandwidth-demanding applications (including virtualization massive file transfer high-speed backup/restoration and multimedia transmission). QNAP's managed and unmanaged 10GbE switches are a perfect match for organizations to build budget-friendly high-speed networks for productive team collaboration. The TVS-872X also include four USB 3.2 Gen 2 ports with up to 10Gb/s transfer speeds allowing compatibility with newer faster USB drives/expansion enclosures for transferring large media files. Get performance benefits from SSD caching and Qtier Technology To attain optimal I/O and reduce latency you can configure SSD caching by using either 2.5-inch SSDs or two M.2 NVMe 2280 SSDs (sold separately) in the TVS-872X. Extra M.2 SSD slots can also be added by installing QM2 PCIe cards allowing you to configure your M.2 SSDs in a RAID 5/6 array to achieve higher sequential speed or a read-only cache speed similar to the performance of a RAID 10 array while maintaining high storage efficiency. SSD over-provisioning (Over-provisioning)
Add additional SSD over-provisioning to avoid write amplification and improve SSD random write speeds and endurance. You can potentially attain enterprise-grade SSD performance levels from affordable consumer-grade SSDs!
SSD cache acceleration
Enables SSD caching for increasing IOPS performance and reducing latency for storage volumes. This is perfect for IOPS-demanding applications including databases and virtualization. |
| Memory Technology | DDR4 SDRAM |
| Number of Network (RJ-45) Ports | 3 |
| Number of Total Expansion Bays | 8 |
| Operating System | QTS 4.5.1 |
| Package Contents | - TVS-872X-I3-8G SAN/NAS Storage System
- 1 x 10GBASE-T Ethernet Cable
- 1 x Power Cord
- Flat Head Screw (for 2.5" HDD)
- Flat Head Screw (for 3.5" HDD)
- 2 x M.2 SSD Heatsinks
- 2 x Drive Tray Keys
- Quick Installation Guide (QIG)
|
| Processor Manufacturer | Intel |
| Processor model | i3-8100T |
| Processor Speed | 3.10 GHz |
| Processor Type | Core i3 |
| Product Model | TVS-872X-I3-8G |
| Product Name | TVS-872X-I3-8G SAN/NAS Storage System |
| Product Series | TVS-x72X |
| Product Type | SAN/NAS Storage System |
| Protocols | SFTP |
| Protocols | WEBDAV |
| Protocols | SSH |
| Protocols | LDAP |
| Protocols | TLS |
| Protocols | RSync |
| Protocols | SMTP |
| Protocols | RTSP |
| Protocols | IPv6 |
| Protocols | IPv4 |
| Protocols | NFS |
| Protocols | DDNS |
| Protocols | DHCP |
| Protocols | iSCSI |
| Protocols | NFSv3 |
| Protocols | FTPS |
| Protocols | BitTorrent |
| Protocols | FTP |
| Protocols | SSL |
| Protocols | SNMPv2 |
| Protocols | HTTPS |
| Protocols | HTTP |
| Protocols | FXP |
| Protocols | UPnP |
| Protocols | PPTP |
| Protocols | NFSv4 |
| Protocols | IPSec |
| Protocols | IPMI |
| Protocols | CIFS/SMB |
| Protocols | DNS |
| Protocols | AFP |
| Protocols | L2TP |
| Protocols | TFTP |
| Protocols | Telnet |
| Protocols | TCP/IP |
| Protocols | SNMP |
| Protocols | SNMPv3 |
| Protocols | SMSC |
| RAID Levels | 0 1 5 6 10 50 60 Hot Spare JBOD |
| RAID Supported | Yes |
| Standard Memory | 8 GB |
| Total Number of USB Ports | 5 |
| UPC Alternates | 885022020973 |
| Weight (Approximate) | 15.56 lb |
| Width | 13" |
