Electro-Voice 2-way Outdoor Speaker - 500 W RMS - White

New

Electro-Voice 2-way Outdoor Speaker - 500 W RMS - White - 2000 W (PMPO) - 12" - 2" Titanium Tweeter - 58 Hz to 19 kHz - 8 Ohm

0 Review(s) Item: EVF-1122S/126-WHT | By: Electro-Voice | 0 In Stock

Sorry This Product is Currently not Available to Buy.

The 2-way Outdoor speakers with the 2000 W power handling work terrifically
Knock yourself out with 500 W RMS power
Listen to deep lows and euphoric highs with a frequency range of sound from 58 Hz-19 kHz
8 Ohm impedance extracts maximum power so you will get more output from your speakers

More Details

Sorry This Product is Currently not Available to Buy.

You may be also interested

Description
Reviews

Electro-Voice 2-way Outdoor Speaker - 500 W RMS - White - 2000 W (PMPO) - 12" - 2" Titanium Tweeter - 58 Hz to 19 kHz - 8 Ohm
2000 W (PMPO) - 12" - 2" Titanium Tweeter - 58 Hz to 19 kHz - 8 Ohm

Product Specifications

Crossover Type	2-way
RMS Output Power	500 W
Speaker Installation	Outdoor
Tweeter Driver Material	Titanium
Tweeter Driver Size	2"
Woofer Diameter	12"
Brand Name	Electro-Voice
Depth	16.27"
Height	30.3"
Impedance	8 Ohm
Manufacturer	The Bosch Group
Manufacturer Part Number	EVF-1122S/126-WHT

Manufacturer Website Address	http://www.bosch.com
Marketing Information	Key Features: Fully Weatherized Fiberglass Finish with Gland Nut and Stainless Steel Grille ND2B 2" (51mm) Diaphragm 1.4" (36mm) Exit Pure Titanium Compression Driver SMX2121 12" (305mm) LF Transducer with Fully Symmetric Drive Advanced 4th Order Crossover Network with HF Protection Coverage Pattern: 120° x 60° Constant Directivity™ 12" Rotatable Waveguide 98 dB Sensitivity 131 dB Maximum SPL System Rating: 500W Continuous (2000W Peak) Active Rating: LF400W/HF40W Continuous (1600W/160W Peak) (22) M10 Threaded Suspension Points General Description: The Electro-Voice® EVF-1122S/126-FG is a fully-weatherized fiberglass-coated high power 2-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in a compact lightweight package. The EVF-1122S/126-FG utilizes the ND2B a high output 2" titanium compression driver coupled to a Constant Directivity™ 120° x 60° waveguide. The SMX2121 12" woofer used FEA optimization for motor suspension and electrical design for very low distortion high efficiency and maximum intelligibility at high SPL levels. The crossover uses steep 24 dB/octave slopes with equalization for very smooth response in vocal range linear off-axis response and a protection circuit for long term reliability. The EVF-1122S/126-FG features make it ideal for many fixed install applications including applications with full exposure to outdoor elements. The trapezoidal enclosure is constructed out of weather resistant birch and coated with fiberglass for maximum protection from extreme outdoor elements. The unique acoustic and rigging design allows for vertical and horizontal clusters to be built using any combination of loudspeakers from the entire EVF & EVH Series with 7 horn patterns to choose from and an assortment of Low Frequency and subwoofer loudspeakers it gives you the tools to maximize flexibility of system design no matter what the application and budget. The innovative input panel provides phoenix style connectors (included in all standard models) and gland nut cover plate (for weatherizing applications). An externally accessible jumper selects passive or active operation. An available 70.7/100 Volt transformer kit simply mounts to the input panel for use in distributed systems. All these features give you the flexibility to do a large range of venues in extreme environments with fewer items in inventory and quickly support your customer's requirements.
Maximum Frequency Response	19 kHz
Minimum Frequency Response	58 Hz
PMPO Output Power	2000 W
Product color	White
Product Name	EVF-1122S 126 12" Loudspeaker
Product Series	EVF
Product Type	Speaker
Sensitivity	131 dB
UPC Alternates	800549698870
Weight (Approximate)	63.05 lb
Width	16"

Material Safety Data Sheet
A Material Safety Data Sheet (MSDS) is a document that contains information on the potential hazards (health, fire, reactivity and environmental) and how to work safely with the chemical product.

Sorry this product does not have any reviews at this time.
