MSI MPG B650 CARBON WIFI Gaming Desktop Motherboard - AMD B650 Chipset - Socket AM5 - ATX
| $344.25 |
- Premium Thermal Design: Heavy plated heatsink with heat-pipe / high quality 7W/mK MOSFET thermal pads / extra choke thermal pads / onboard M.2 Shield Frozr.
- Latest DDR5 Memory: A huge step of DDR performance enhancement with the latest DDR5 memory and MSI Memory Boost technology.
- Lightning Gen 5 Solution: The latest Gen 5 M.2 solution with up to 128GB/s bandwidth for maximum transfer speed.
- M.2 Shield FROZR: M.2 thermal accessory keeps M.2 SSDs safe while preventing throttling, making them run faster.
- Wi-Fi 6E: The latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS color technology, delivering speeds up to 2400Mbps.
- 2.5G Network Solution: Featuring premium 2.5G LAN to deliver better network experience.
- Lightning USB 20G: Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1.
- Audio Boost 5: Isolated audio with a high quality audio processor for the most immersi
| Buy Once $344.25 | |||
| Subscribe & Save$327.04 | |||
| Delivery Ferquency |
Ryzen 5, Ryzen 7, Ryzen 9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - UDIMM, DIMM - 4 x Memory Slots - IEEE 802.11 a/b/g/n/ac/ax - HDMI - DisplayPort - 6 x SATA Interfaces
Product Specifications
| Chipset Manufacturer | AMD |
| Chipset Model | B650 |
| Maximum Memory Supported | 128 GB |
| Memory Speed Supported | 5400 MHz |
| Number of Memory Slots | 4 |
| Number of PCI Express x16 Slots | 2 |
| Number of SATA Interfaces | 6 |
| Number of Total Expansion Slots | 3 |
| Onboard Video | CPU Dependent Video |
| Processor Socket | Socket AM5 |
| Processor Supported | Ryzen 9 |
| S/PDIF | Yes |
| Total Number of Onboard USB Ports | 7 |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Audio Channels | 7.1 |
| Controller Type | Serial ATA/600 |
| Country of origin | China |
| Depth | 9.6" |
| Form factor | ATX |
| Limited Warranty | 3 Year |
| Manufacturer | MSI |
| Manufacturer Part Number | B650CARWIFI |
| Manufacturer Website Address | http://www.msi.com |
| Marketing Information | MPG B650 CARBON WIFI MPG B650 CARBON WIFI employs carbon black color scheme and RGB lighting to show off different personality and identity. Besides being stylish it is also powerful. BE AHEAD POP YOUR STYLE The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style the MPG series defines the future of gaming fashion. |
| Memory form factor | UDIMM |
| Memory form factor | DIMM |
| Memory Technology | DDR5 SDRAM |
| Product Line | MPG |
| Product Model | B650 CARBON WIFI |
| Product Name | MPG B650 CARBON WIFI Gaming Desktop Motherboard |
| Product Type | Gaming Desktop Motherboard |
| RAID Levels | 10 |
| RAID Levels | 0 |
| RAID Levels | 1 |
| UPC Alternates | 824142301067 |
| Width | 12" |
