TRENDnet 100Base-TX to 100Base-FX Single Mode SC Fiber Media Converter (15 Km / 9.3 Miles);TFC-110S15; Auto-Negotiation; Auto-MDIX; Full-Duplex Mode; Fiber to Ethernet Converter; Lifetime Protection - 10/100Base-TX to 100Base-FX Fiber Converter (15km)
10/100Base-TX to 100Base-FX Fiber Converter (15km)
| Fiber Mode Supported | Single-mode |
| Maximum Distance Supported | 9.32 Mile |
| Network (RJ-45) | Yes |
| Additional Information | - Wavelength: 1300nm
- Protocol: CSMA/CD
- Supported Frame Size: Standard Ethernet up to 1522-Byte
- The fiber connection can be multi-mode SC MT-RJ
- Optional 19" system chassis with redundant power supply (TFC-1600) holds up to 16 TFC series Media Converters
Used with TFC1600. TFC-1600 is a 19" system chassis. holds up to 16 TFC series Media Converters TFC-110MSC TFC-110MST TFC110S15 TFC-110S30 and TFC-1000MSC |
| Certifications & Standards | - IEEE 802.3: 10Base-T
- IEEE 802.3u: 100Base-TX and 100Base-FX
- FCC
- CE
- VCCI
|
| Country of origin | China |
| Depth | 17" |
| Ethernet Technology | Fast Ethernet |
| Form factor | Rack-mountable |
| Form factor | Wall Mountable |
| Height | 5" |
| Input voltage | 7.5 V DC |
| Limited Warranty | 3 Year Lifetime |
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TFC-110S15 |
| Manufacturer Website Address | http://www.trendnet.com |
| Marketing Information | - The TFC-110S15 Fiber Converter works with the TFC-1600 chassis system or as a standalone unit
- This converter is a Single Mode SC-Type fiber converter spanning distances up to 15km (9.3 miles)
- Ports include 1 x 10/100Base-TX (RJ-45) port and 1 x 100Base-FX fiber port (SC-Type)
- One 10/100 Base-TX auto-negotiation RJ-45 port
- Auto-negotiation 10/100 Mbps connection speed and half/full-duplex mode on TX port
- One 100 Mbps fiber port with single-mode SC-type connector
- Half/full-duplex mode selector on fiber port
- Status LED indicators for power link/activity full-duplex and speed
The TFC-110S15 Fiber Converter works with the TFC-1600 chassis system or as a standalone unit. This converter is a Single Mode SC-Type fiber converter spanning distances up to 15km (9.3 miles). Ports include 1 x 10/100Base-TX (RJ-45) port and 1 x 100Base-FX fiber port (SC-Type).
Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards
1 x 10/100Base-TX auto-negotiation RJ-45 port
Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port
Auto MDIX for 10/100Base-TX port
1 x 100Mbps fiber port with single-mode SC-type connector
Status LED indicators for Power Link/Activity Full-Duplex and Speed
Dip-switch for full and half duplex selection on fiber port
Optional 19" system chassis with redundant power supply (TFC-1600) holds up to 16 TFC series Media Converters
Lifetime TRENDnet Manufacturer's Warranty
PACKAGE CONTENTS
TFC-110S15
Multi-Language Quick Installation Guide
Power Adapter (5V 1A) More from the Manufacturer |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Network Technology | 100Base-FX |
| Network Technology | 10/100Base-TX |
| Number of Network (RJ-45) Ports | 1 |
| Power consumption | 7.20 W |
| Product Condition | New |
| Product Name | 10/100Base-TX to 100Base-FX Single Mode Fiber Converter (15KM) |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 2 |
| UPC Alternates | 710931504064 710931981445 818230518758 |
| Weight (Approximate) | 8.80 lb |
| Width | 12" |
