| Connector Type on First End | Bare Wire |
| Insulation Material | Foam Polyethlene (FPE) |
| Insulation Material | Foam Polyethlene (FPE) |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Jacket Material | Polyvinyl Chloride (PVC) |
| American Wire Gauge | 23 AWG |
| American Wire Gauge | 23 AWG |
| Brand Name | PanNet |
| Brand Name | PanNet |
| Cable length | 1000.66 ft |
| Cable length | 1000.66 ft |
| Cable type | Category 6a |
| Cable type | Category 6a |
| Color | Gray |
| Color | Gray |
| Conductor | Copper |
| Conductor | Copper |
| Connector on First End | Bare Wire |
| Connector on First End | Bare Wire |
| Data transfer rate | 10 Gbit/s |
| Data transfer rate | 10 Gbit/s |
| Device Supported | Network Device |
| Device Supported | Network Device |
| Features | EMI Protection |
| Features | Alien Cross Talk (AXT) |
| Features | PoE+ |
| Features | Bendable |
| Features | Vari-MaTriX |
| Features | PoE++ |
| Features | PoE+ |
| Features | Bendable |
| Features | Vari-MaTriX |
| Features | PoE++ |
| Features | PoE |
| Features | Flame Retardant |
| Features | EMI Protection |
| Features | Alien Cross Talk (AXT) |
| Features | PoE |
| Features | Flame Retardant |
| Jacket Type | Plenum |
| Jacket Type | Plenum |
| Jacket Type | CMP |
| Jacket Type | CMP |
| Limited Warranty | 1 Year |
| Limited Warranty | 1 Year |
| Manufacturer | PANDUIT CORP |
| Manufacturer | PANDUIT CORP |
| Manufacturer Part Number | PUP6AHD04IG-G |
| Manufacturer Part Number | PUP6AHD04IG-G |
| Manufacturer Website Address | http://www.panduit.com |
| Manufacturer Website Address | http://www.panduit.com |
| Marketing Information | The Vari-MaTriX HD copper cable is the smallest Category 6A copper cable on the market. With a 0.230" diameter the Category 6A Vari-MaTriX HD is equivalent in size to a Category 6 cable. Upgrading from Category 6 to 6A is simplified as the Vari-Matrix HD increases cable fill up to 35% and can utilize existing Category 6-sized pathways. The Vari-MaTriX tape shall minimize the cable diameter and suppress the effects of alien crosstalk while retaining UTP electromagnetic interference immunity. The small cable diameter shall maximize cable density such that existing pathways can be utilized when upgrading from Category 6 cabling. |
| Marketing Information | The Vari-MaTriX HD copper cable is the smallest Category 6A copper cable on the market. With a 0.230" diameter the Category 6A Vari-MaTriX HD is equivalent in size to a Category 6 cable. Upgrading from Category 6 to 6A is simplified as the Vari-Matrix HD increases cable fill up to 35% and can utilize existing Category 6-sized pathways. The Vari-MaTriX tape shall minimize the cable diameter and suppress the effects of alien crosstalk while retaining UTP electromagnetic interference immunity. The small cable diameter shall maximize cable density such that existing pathways can be utilized when upgrading from Category 6 cabling. |
| Packaged Quantity | 1000 |
| Packaged Quantity | 1000 |
| Product color | Gray |
| Product Line | TX6A 10Gig |
| Product Line | TX6A 10Gig |
| Product Name | Pan-Net Copper Cable |
| Product Name | Pan-Net Copper Cable |
| Product Type | Network Cable |
| Product Type | Network Cable |
| Shielding | No |
| Shielding | No |
| UPC Alternates | 061305679278 |
| UPC Alternates | 061305679278 |
| Weight (Approximate) | 30 lb |
| Weight (Approximate) | 30 lb |
