Cisco Nexus 93120TX Layer 3 Switch - 96 Ports - Manageable - 10 Gigabit Ethernet, 40 Gigabit Ethernet - 10GBase-T, 40GBase-X - 3 Layer Supported - Modular - Power Supply - Optical Fiber, Twisted Pair - 2U High - Rack-mountable - 1 Year Limited Warranty
96 Ports - Manageable - 10 Gigabit Ethernet, 40 Gigabit Ethernet - 10GBase-T, 40GBase-X - 3 Layer Supported - Modular - Power Supply - Optical Fiber, Twisted Pair - 2U High - Rack-mountable - 1 Year Limited Warranty
| Compatible Rack Unit | 2U |
| Number of Total Expansion Slots | 6 |
| Total Number of Network Ports | 96 |
| Brand Name | Cisco |
| Depth | 17.5" |
| Environmental Certification | RoHS-6 |
| Ethernet Technology | 40 Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Expansion Slot Type | QSFP+ |
| Form factor | Rack-mountable |
| Height | 3.5" |
| Layer Supported | 3 |
| Limited Warranty | 1 Year |
| Manageable | Yes |
| Manufacturer | Cisco Systems Inc |
| Manufacturer Part Number | C1-N9K-C93120TX |
| Manufacturer Website Address | http://www.cisco.com |
| Marketing Information | Organizations everywhere recognize that changing application environments are creating new demands for the IT infrastructure that supports them. Application workloads are deployed across a mix of virtualized and nonvirtualized server and storage infrastructure requiring a network infrastructure that provides consistent connectivity security and visibility across a range of bare-metal virtualized and cloud computing environments: - Application instances are created dynamically. As a result the provisioning modification and removal of application network connectivity needs to be dynamic as well.
- Business units demand accelerated application deployments. IT departments have to provide shared IT infrastructure to address time-to-market needs and to increase their return on investment (ROI).
- With organizations deploying a mix of custom open source and off-the-shelf commercial applications IT departments must manage both security and quality of service (QoS) for environments that support multitenancy.
- Applications have been transitioning over time to a less monolithic scale-out multinode model. IT infrastructure that supports this model must scale with the speed of business and support both 10 and 40 Gigabit Ethernet connectivity.
The Cisco Nexus® 9000 Series Switches include both modular and fixed-port switches that are designed to overcome these challenges with a flexible agile low-cost application-centric infrastructure (ACI). The Cisco Nexus 9300 platform consists of fixed-port switches designed for top-of-rack (ToR) and middle-of-row (MoR) deployment in data centers that support enterprise applications service provider hosting and cloud computing environments. The switches are Layer 2 and 3 nonblocking 10 and 40 Gigabit Ethernet and Fibre Channel over Ethernet (FCoE)-capable switches with up to 2.56 terabits per second (Tbps) of internal bandwidth. |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Network Technology | 40GBase-X |
| Network Technology | 10GBase-T |
| Port/Expansion Slot Details | 6 x 40 Gigabit Ethernet Expansion Slot |
| Port/Expansion Slot Details | 96 x 10 Gigabit Ethernet Network |
| Power source | Power Supply |
| Product Family | Nexus 9300 |
| Product Line | Nexus |
| Product Model | 93120TX |
| Product Name | Nexus 93120TX Layer 3 Switch |
| Product Series | 9300 |
| Product Type | Layer 3 Switch |
| Uplink Port | No |
| Weight (Approximate) | 26.01 lb |
| Width | 22.5" |
