Transition Networks Coarse Wavelength Division Multiplexing (CWDM) 4 Channels + OSC Duplex LC
| $1,004.48 |
- Increase bandwidth on existing fiber infrastructure
- Alleviate fiber exhaustion
- Transmit multiple protocols over an existing duplex fiber link by combining the fiber outputs of multiple media converters
- Provide scalable bandwidth of up to 10 Gbps per channel over existing fiber links
- Plug-and-Play, no configuration of CWDM components
- Use existing standard optical ports on switches and routers: Utilize Optical Line Converter as transponder
- 1 RU rack mountable chassis to hold 2 CWDM modules
4 Data Channels - Optical Fiber - Gigabit Ethernet
Product Specifications
| Fiber Optic Wavelength | 1570 nm |
| Fiber Optic Wavelength | 1530 nm |
| Fiber Optic Wavelength | 1570 nm |
| Fiber Optic Wavelength | 1530 nm |
| Fiber Optic Wavelength | 1510 nm |
| Fiber Optic Wavelength | 1550 nm |
| Fiber Optic Wavelength | 1550 nm |
| Fiber Optic Wavelength | 1510 nm |
| LC Port Type | Duplex |
| LC Port Type | Duplex |
| Network Technology Supported | 10GBase-X |
| Network Technology Supported | 10GBase-X |
| Number of Data Channels | 4 |
| Number of Data Channels | 4 |
| Rack Width | 19" |
| Rack Width | 19" |
| Brand Name | Transition Networks |
| Brand Name | Transition Networks |
| Connectivity technology | Wired |
| Connectivity technology | Wired |
| Country of origin | China |
| Country of origin | China |
| Depth | 7.7" |
| Depth | 7.7" |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Form factor | Rack-mountable |
| Form factor | Rack-mountable |
| Height | 1.2" |
| Height | 1.2" |
| Limited Warranty | Lifetime |
| Limited Warranty | Lifetime |
| Manufacturer | Transition Networks Inc |
| Manufacturer | Transition Networks Inc |
| Manufacturer Part Number | CWDM-M551LCR-B |
| Manufacturer Part Number | CWDM-M551LCR-B |
| Manufacturer Website Address | http://www.transition.com |
| Manufacturer Website Address | http://www.transition.com |
| Marketing Information | Transition Networks CWDM products uses a passive technology that allows for any protocol to be transported over the fiber link as long as it is at a specific wavelength. Transition Networks' WDM Mux/Demux and Add/Drop Mux can provide a simple and affordable method to maximize existing fiber capacity with little or no increased cost. |
| Marketing Information | Transition Networks CWDM products uses a passive technology that allows for any protocol to be transported over the fiber link as long as it is at a specific wavelength. Transition Networks' WDM Mux/Demux and Add/Drop Mux can provide a simple and affordable method to maximize existing fiber capacity with little or no increased cost. |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Optical Fiber |
| Product Name | Coarse Wavelength Division Multiplexing (CWDM) 4 Channels + OSC Duplex LC |
| Product Name | Coarse Wavelength Division Multiplexing (CWDM) 4 Channels + OSC Duplex LC |
| Product Type | Data Multiplexer/Demultiplexer |
| Product Type | Data Multiplexer/Demultiplexer |
| Rack Height | 1U |
| Rack Height | 1U |
| UPC Alternates | 648177043149 |
| UPC Alternates | 648177043149 |
| Weight (Approximate) | 14.08 oz |
| Weight (Approximate) | 14.08 oz |
| Width | 8.5" |
| Width | 8.5" |
