Transition Networks SPOEB1039-105 Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x LC Ports - DuplexLC Port - Multi-mode - Fast Ethernet - 10/100Base-T, 100Base-FX - 1.24 Mile - Power Supply - Wall Mountable, Rail-mountable
1 x Network (RJ-45) - 1 x LC Ports - DuplexLC Port - Multi-mode - Fast Ethernet - 10/100Base-T, 100Base-FX - 1.24 Mile - Power Supply - Wall Mountable, Rail-mountable
| Fiber Mode Supported | Multi-mode |
| Fiber Mode Supported | Multi-mode |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Wavelength | 1300 nm |
| Fiber Optic Wavelength | 1300 nm |
| Fiber Optic Wavelength | 1300 nm |
| LC Port Type | Duplex |
| LC Port Type | Duplex |
| LC Port Type | Duplex |
| Maximum Distance Supported | 1.24 Mile |
| Maximum Distance Supported | 1.24 Mile |
| Maximum Distance Supported | 1.24 Mile |
| Brand Name | Transition Networks |
| Brand Name | Transition Networks |
| Brand Name | Transition Networks |
| Country of origin | Taiwan |
| Country of origin | Taiwan |
| Country of origin | Taiwan |
| Depth | 4.8" |
| Depth | 4.8" |
| Depth | 4.8" |
| Environmental Certification | WEEE |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Fast Ethernet |
| Ethernet Technology | Fast Ethernet |
| Ethernet Technology | Fast Ethernet |
| Form factor | Rail-mountable |
| Form factor | Wall Mountable |
| Form factor | Wall Mountable |
| Form factor | Rail-mountable |
| Form factor | Wall Mountable |
| Form factor | Rail-mountable |
| Height | 1" |
| Height | 1" |
| Height | 1" |
| Limited Warranty | Lifetime |
| Limited Warranty | Lifetime |
| Limited Warranty | Lifetime |
| Manufacturer | Transition Networks Inc |
| Manufacturer | Transition Networks Inc |
| Manufacturer | Transition Networks Inc |
| Manufacturer Part Number | SPOEB1039-105-EU |
| Manufacturer Part Number | SPOEB1039-105-EU |
| Manufacturer Part Number | SPOEB1039-105-EU |
| Manufacturer Website Address | http://www.transition.com |
| Manufacturer Website Address | http://www.transition.com |
| Manufacturer Website Address | http://www.transition.com |
| Marketing Information | SPOEB10xx-105 is a 10/100 Ethernet copper to fiber PoE media converter that enables enterprises to provide power to network devices over the existing CAT5 data connection.
Transition Networks' AC powered PoE media converters combine data received over a fiber optic link with
-48 VDC power; providing power to Data Terminal Equipment (DTE) Power Devices (PD) over unshielded twisted pair cable. The PoE converters are Power Sourcing Equipment (PSE) and are fully compatible with Powered Devices (PD) that comply with the IEEE 802.3af: 2003 standard. The converters also include a PD signature sensing and power monitoring features per the IEEE 802.3af standard. Other features include Over-Current Protection Under-Current Detection and Fault Protection Input.
This feature enhanced model offers the ability to enable/disable many of the features as well as force port capabilities.
In addition with the PSE/LPT switch enabled a loss of Fiber RX will disable PSE power output on the UTP port for 2 seconds to allow remote device to re-initialize. (Also known as Powered Device Reset.)
The PoE converter is fully compatible with devices that comply with the IEEE
802.3af standard. The PoE converter is capable of inserting power on data pairs or spare pair of the MDI. |
| Marketing Information | SPOEB10xx-105 is a 10/100 Ethernet copper to fiber PoE media converter that enables enterprises to provide power to network devices over the existing CAT5 data connection.
Transition Networks' AC powered PoE media converters combine data received over a fiber optic link with
-48 VDC power; providing power to Data Terminal Equipment (DTE) Power Devices (PD) over unshielded twisted pair cable. The PoE converters are Power Sourcing Equipment (PSE) and are fully compatible with Powered Devices (PD) that comply with the IEEE 802.3af: 2003 standard. The converters also include a PD signature sensing and power monitoring features per the IEEE 802.3af standard. Other features include Over-Current Protection Under-Current Detection and Fault Protection Input.
This feature enhanced model offers the ability to enable/disable many of the features as well as force port capabilities.
In addition with the PSE/LPT switch enabled a loss of Fiber RX will disable PSE power output on the UTP port for 2 seconds to allow remote device to re-initialize. (Also known as Powered Device Reset.)
The PoE converter is fully compatible with devices that comply with the IEEE
802.3af standard. The PoE converter is capable of inserting power on data pairs or spare pair of the MDI. |
| Marketing Information | SPOEB10xx-105 is a 10/100 Ethernet copper to fiber PoE media converter that enables enterprises to provide power to network devices over the existing CAT5 data connection.
Transition Networks' AC powered PoE media converters combine data received over a fiber optic link with
-48 VDC power; providing power to Data Terminal Equipment (DTE) Power Devices (PD) over unshielded twisted pair cable. The PoE converters are Power Sourcing Equipment (PSE) and are fully compatible with Powered Devices (PD) that comply with the IEEE 802.3af: 2003 standard. The converters also include a PD signature sensing and power monitoring features per the IEEE 802.3af standard. Other features include Over-Current Protection Under-Current Detection and Fault Protection Input.
This feature enhanced model offers the ability to enable/disable many of the features as well as force port capabilities.
In addition with the PSE/LPT switch enabled a loss of Fiber RX will disable PSE power output on the UTP port for 2 seconds to allow remote device to re-initialize. (Also known as Powered Device Reset.)
The PoE converter is fully compatible with devices that comply with the IEEE
802.3af standard. The PoE converter is capable of inserting power on data pairs or spare pair of the MDI. |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Twisted Pair |
| Network Technology | 100Base-FX |
| Network Technology | 10/100Base-T |
| Network Technology | 10/100Base-T |
| Network Technology | 100Base-FX |
| Network Technology | 100Base-FX |
| Network Technology | 10/100Base-T |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Package Contents | - SPOEB1039-105 Transceiver/Media Converter
- Power Supply
|
| Package Contents | - SPOEB1039-105 Transceiver/Media Converter
- Power Supply
|
| Package Contents | - SPOEB1039-105 Transceiver/Media Converter
- Power Supply
|
| Power source | Power Supply |
| Power source | Power Supply |
| Power source | Power Supply |
| Product Model | SPOEB1039-105 |
| Product Model | SPOEB1039-105 |
| Product Model | SPOEB1039-105 |
| Product Name | SPOEB1039-105 Transceiver/Media Converter |
| Product Name | SPOEB1039-105 Transceiver/Media Converter |
| Product Name | SPOEB1039-105 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 2 |
| Total Number of Ports | 2 |
| Total Number of Ports | 2 |
| UPC Alternates | 648177041077 |
| UPC Alternates | 648177041077 |
| UPC Alternates | 648177041077 |
| USB | No |
| USB | No |
| USB | No |
| Weight (Approximate) | 2 lb |
| Weight (Approximate) | 2 lb |
| Weight (Approximate) | 2 lb |
