Allied Telesis DMC AT-DMC100/LC-90 Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x LC Ports - DuplexLC Port - Multi-mode - Fast Ethernet - 10/100Base-T, 100Base-FX - Desktop, Wall Mountable
1 x Network (RJ-45) - 1 x LC Ports - DuplexLC Port - Multi-mode - Fast Ethernet - 10/100Base-T, 100Base-FX - Desktop, Wall Mountable
| Fiber Mode Supported | Multi-mode |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Standard | 50/125 µm |
| Fiber Optic Cable Standard | 62.5/125 µm |
| Fiber Optic Cable Standard | 62.5/125 µm |
| Fiber Optic Cable Standard | 50/125 µm |
| LC Port Type | Duplex |
| LC Port Type | Duplex |
| Maximum Distance Supported | 1804.46 ft |
| Maximum Distance Supported | 1804.46 ft |
| Brand Name | Allied Telesis |
| Brand Name | Allied Telesis |
| Depth | 3.6" |
| Depth | 3.6" |
| Environmental Certification | RoHS |
| Environmental Certification | REACH |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmental Certification | REACH |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Fast Ethernet |
| Ethernet Technology | Fast Ethernet |
| Form factor | Wall Mountable |
| Form factor | Wall Mountable |
| Form factor | Desktop |
| Form factor | Desktop |
| Height | 0.9" |
| Height | 0.9" |
| Manufacturer | Allied Telesis Inc |
| Manufacturer | Allied Telesis Inc |
| Manufacturer Part Number | AT-DMC100/LC-90 |
| Manufacturer Part Number | AT-DMC100/LC-90 |
| Manufacturer Website Address | http://www.alliedtelesis.com |
| Manufacturer Website Address | http://www.alliedtelesis.com |
| Marketing Information | Desktop USB-Powered Media Converters
The Allied Telesis DMC Series of Gigabit mini media converters are among the smallest media converters in the market today. Overview At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high Allied Telesis DMC Series media converters can easily fit into the palm of a hand. In addition to being compact-with a small carbon footprint-the DMC Series can also be powered with the included Micro USB to USB cable and plugged directly into a laptop or PC or may also be powered via the optional AC/DC adapter. This saves installation time and cabling as there are no further power requirements. Fiber Connections The Allied Telesis range of Gigabit media converters provides a complete family of conversion devices allowing users to extend the size of UTP networks with the use of fiber cabling. Supporting SC ST and LC fiber connectors these converters can be used to extend networks with up to 500m of multi-mode fiber. |
| Marketing Information | Desktop USB-Powered Media Converters
The Allied Telesis DMC Series of Gigabit mini media converters are among the smallest media converters in the market today. Overview At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high Allied Telesis DMC Series media converters can easily fit into the palm of a hand. In addition to being compact-with a small carbon footprint-the DMC Series can also be powered with the included Micro USB to USB cable and plugged directly into a laptop or PC or may also be powered via the optional AC/DC adapter. This saves installation time and cabling as there are no further power requirements. Fiber Connections The Allied Telesis range of Gigabit media converters provides a complete family of conversion devices allowing users to extend the size of UTP networks with the use of fiber cabling. Supporting SC ST and LC fiber connectors these converters can be used to extend networks with up to 500m of multi-mode fiber. |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Network Technology | 10/100Base-T |
| Network Technology | 100Base-FX |
| Network Technology | 10/100Base-T |
| Network Technology | 100Base-FX |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Package Contents | - DMC AT-DMC100/LC-90 Transceiver/Media Converter
- Micro USB to USB cable
- Power Supply
|
| Package Contents | - DMC AT-DMC100/LC-90 Transceiver/Media Converter
- Micro USB to USB cable
- Power Supply
|
| Power source | USB |
| Power source | USB |
| Product Name | DMC AT-DMC100/LC-90 Transceiver/Media Converter |
| Product Name | DMC AT-DMC100/LC-90 Transceiver/Media Converter |
| Product Series | DMC |
| Product Series | DMC |
| Product Type | Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 2 |
| Total Number of Ports | 2 |
| UPC Alternates | 767035209937 818242248711 |
| UPC Alternates | 767035209937 818242248711 |
| USB | No |
| USB | No |
| Weight (Approximate) | 4 oz |
| Weight (Approximate) | 4 oz |
| Width | 1.3" |
| Width | 1.3" |
