SmartAVI DVX200 Cat6 DVI Video Console/Extender - 1 x 1 - WUXGA, SXGA, UXGA - 220ft
1 x 1 - WUXGA, SXGA, UXGA - 220ft
| Network (RJ-45) | Yes |
| Number of DVI Outputs | 1 |
| Transmitter Depth | 3.40" |
| Transmitter Height | 0.80" |
| Transmitter Weight (Approximate) | 3.20 oz |
| Transmitter Width | 2.75" |
| Brand Name | SmartAVI |
| Connectivity technology | Wired |
| Country of origin | United States |
| Form factor | Rack-mountable |
| Graphics Modes | WUXGA |
| Limited Warranty | 1 Year |
| Manufacturer | Smart Audio Video Innovation |
| Manufacturer Part Number | DVX-200PS |
| Manufacturer Website Address | http://www.smartavi.com |
| Marketing Information | SmartAVI's DVX-200 extends DVI-D signals up to 225 feet away via inexpensive CAT5 cables. Affordable DVI-D Signal Extension The DVX-200 is capable of sending 1080p (1920x1080) full HD resolution DVI-D video up to 225 feet away from source devices without risk of delay or interference. Better yet the DVX-200 is compatible with all major operating systems and all SmartAVI KVM solutions perfect for expanding the range of remote keyboard-video-mouse operation. Best of all the DVX-200 is a highly affordable extension solution thanks to its reliable and popular CAT5 cabling. Cost-conscious users will find a lot to love about the high speed and performance of CAT5 extension which lands at a fraction of the cost of other comparable extender types.
Features: - Top Image Quality at all Resolutions.
- Video Resolutions up to 1920 x 1200 @ 60Hz (1280 x 1024 @ 75Hz) up to the maximum distance.
- User Selectable: DCC-Information MAC or PC
- Distances: 225 ft with Cat6 23AWG STP cable.
- Compatible with all operating systems.
- Compatible with all major KVM Switches.
- Rack Mount options (19)
- Supports MAC and PC DVI-D
- No Degradation of Video Quality
- LEDs Indicate Power and Loss of clock Signal
- External Power Supplies
- Silent Fanless Operation
|
| Maximum Operating Distance | 225 ft |
| Maximum Video Resolution | 1920 x 1200 |
| Media Type Supported | Twisted Pair |
| Number of Network (RJ-45) Ports | 2 |
| Package Contents | - 1 x DVX-200-TX Transmitter Unit
- 1 x DVX-200-RX Receiver Unit
- 2 x Extender unit Power Supplies
- Dual-Link DVI M/M Cable
- 1 x Quick Start and Installation Guide
|
| Product Name | DVI-D/PC CAT6 STP Extender |
| Product Type | Video Extender Transmitter/Receiver |
| Twisted Pair Cable Standard | Category 6 |
| UPC Alternates | 638936941526 813280014113 |
