Tripp Lite Hardened Gigabit Fiber to Ethernet Media Converter 10/100/1000 Mbps RJ45/SFP -10° to 60°C DC Power - 1 x Network (RJ-45) - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 1 x Expansion Slots - SFP (mini-GBIC) - 1 x SFP Slots - DIN Rail Mountable - TAA Compliant
1 x Network (RJ-45) - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 1 x Expansion Slots - SFP (mini-GBIC) - 1 x SFP Slots - DIN Rail Mountable - TAA Compliant
| Fiber Mode Supported | Single-mode |
| Fiber Mode Supported | Multi-mode |
| Fiber Mode Supported | Single-mode |
| Fiber Mode Supported | Multi-mode |
| Number of Total Expansion Slots | 1 |
| Number of Total Expansion Slots | 1 |
| Brand Name | Tripp Lite |
| Brand Name | Tripp Lite |
| Country of origin | Taiwan |
| Country of origin | Taiwan |
| Depth | 3.9" |
| Depth | 3.9" |
| Environmental Certification | RoHS |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Expansion Slot Type | SFP (mini-GBIC) |
| Expansion Slot Type | SFP (mini-GBIC) |
| Form factor | DIN Rail Mountable |
| Form factor | DIN Rail Mountable |
| Height | 2" |
| Height | 2" |
| Limited Warranty | 2 Year |
| Limited Warranty | 2 Year |
| Manufacturer | Tripp Lite by Eaton |
| Manufacturer | Tripp Lite by Eaton |
| Manufacturer Part Number | N785-H01-SFP-D |
| Manufacturer Part Number | N785-H01-SFP-D |
| Manufacturer Website Address | http://www.tripplite.com |
| Manufacturer Website Address | http://www.tripplite.com |
| Marketing Information | Features | Customize a Network Connection Extension over Fiber Optic Cable
This network media converter works with a variety of SFP transceivers to convert a copper Gigabit Ethernet signal to fiber optic and extend it to a second network device. The customizable SFP port supports both singlemode and multimode transceivers allowing your network connection to reach hubs switches and other devices located farther away than copper cabling's 100-meter limit. Auto-negotiation and automatic MDI/MDI-X configuration seamlessly connect devices without crossover cabling. Monitor Your Installation with Line Loop Back
Determine the health of your network connection via the Line Loop Back (LLB) function which ensures copper and fiber cables have been correctly installed. Use the DIP switches to control each function or turn them on or off. LEDs Indicate Installation Performance and Diagnostic Functions
Easy-to-read LEDs on the side of the unit indicate essential status information including network speed and connection LFS diagnostics and unit power. The included 20-57VDC terminal block provides primary and secondary power inputs. Protective Metal Housing Built to Withstand a Variety of Hazards
The hardened aluminum case is designed to operate in extreme temperatures ranging from -10 to 60 degrees Celsius (14 to 140 degrees Fahrenheit). It is protected from electrostatic discharge (ESD) radio frequency interference (RFI) and power surges. Hardware is included for DIN mounting. TAA-Compliant for GSA Schedule Purchases
The N785-H01-SFP-D is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts. |
| Marketing Information | Features | Customize a Network Connection Extension over Fiber Optic Cable
This network media converter works with a variety of SFP transceivers to convert a copper Gigabit Ethernet signal to fiber optic and extend it to a second network device. The customizable SFP port supports both singlemode and multimode transceivers allowing your network connection to reach hubs switches and other devices located farther away than copper cabling's 100-meter limit. Auto-negotiation and automatic MDI/MDI-X configuration seamlessly connect devices without crossover cabling. Monitor Your Installation with Line Loop Back
Determine the health of your network connection via the Line Loop Back (LLB) function which ensures copper and fiber cables have been correctly installed. Use the DIP switches to control each function or turn them on or off. LEDs Indicate Installation Performance and Diagnostic Functions
Easy-to-read LEDs on the side of the unit indicate essential status information including network speed and connection LFS diagnostics and unit power. The included 20-57VDC terminal block provides primary and secondary power inputs. Protective Metal Housing Built to Withstand a Variety of Hazards
The hardened aluminum case is designed to operate in extreme temperatures ranging from -10 to 60 degrees Celsius (14 to 140 degrees Fahrenheit). It is protected from electrostatic discharge (ESD) radio frequency interference (RFI) and power surges. Hardware is included for DIN mounting. TAA-Compliant for GSA Schedule Purchases
The N785-H01-SFP-D is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts. |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Twisted Pair |
| Network Technology | 100/1000Base-X |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 100/1000Base-X |
| Network Technology | 10/100/1000Base-T |
| Package Contents | - N785-H01-SFP-D Transceiver/Media Converter
- SFP Connector Cap
- RJ45 Connector Cap
- Terminal Block (20-57VDC)
- DIN Rail Kit
- Quick Start Guide
|
| Package Contents | - N785-H01-SFP-D Transceiver/Media Converter
- SFP Connector Cap
- RJ45 Connector Cap
- Terminal Block (20-57VDC)
- DIN Rail Kit
- Quick Start Guide
|
| Plug/Connector Type | Terminal Block |
| Plug/Connector Type | Terminal Block |
| Power consumption | 5.50 W |
| Power consumption | 5.50 W |
| Power source | DC |
| Power source | DC |
| Product Name | N785-H01-SFP-D Transceiver/Media Converter |
| Product Name | N785-H01-SFP-D Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| UPC Alternates | 037332268570 |
| UPC Alternates | 037332268570 |
| Weight (Approximate) | 14.88 oz |
| Weight (Approximate) | 14.88 oz |
| Width | 4.6" |
| Width | 4.6" |
