Club 3D MST Hub DisplayPort 1.4 to DisplayPort + HDMI 4K60Hz M/F - 1 x DisplayPort 1.4 Digital Audio/Video -Male, 1 x Micro USB - Female - 1 x DisplayPort 1.4 Digital Audio/Video - Female, 1 x HDMI Digital Audio/Video - Female - 3840 x 2160 Supported - Black
1 x DisplayPort 1.4 Digital Audio/Video -Male, 1 x Micro USB - Female - 1 x DisplayPort 1.4 Digital Audio/Video - Female, 1 x HDMI Digital Audio/Video - Female - 3840 x 2160 Supported - Black
| Connector Gender on First End | Male |
| Connector Gender on Second End | Female |
| Connector on First End Details | 1 x Micro USB - Female |
| Connector on First End Details | 1 x DisplayPort 1.4 Digital Audio/Video -Male |
| Connector on Second End Details | 1 x DisplayPort 1.4 Digital Audio/Video - Female |
| Connector on Second End Details | 1 x HDMI Digital Audio/Video - Female |
| Connector Type on First End | Micro USB - Female |
| Connector Type on First End | DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Type on Second End | DisplayPort 1.4 Digital Audio/Video - Female |
| Connector Type on Second End | HDMI Digital Audio/Video - Female |
| Adapter Type | DisplayPort/HDMI |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Features | Multi-Stream Transport (MST) Support |
| Features | HDCP 2.2 |
| Features | Single Stream Transport (SST) |
| Manufacturer | Club 3D |
| Manufacturer Part Number | CSV-7220 |
| Manufacturer Website Address | http://www.club-3d.nl |
| Marketing Information | The CSV-7220 is a MST hub DisplayPort™ 1.4 to DisplayPort™ + HDMI™ 4K60Hz M/F. This DisplayPort™ 1.4 MST hub is designed to cater for your most versatile connectivity demands such as tablets laptops etc. with a free DP™ (DisplayPort) port.
Give your device more displays. PCs and notebooks are increasingly becoming more powerful and smaller in the physical form factor. With a single DP™1.4 port available you can now drive one-Displayport™ screen simultaneously with an HDMI™ screen at 4K60Hz or One DP™ display at 8K30Hz in MST mode Windows. All it needs is a free DP™ 1.4 port on your Laptop or PC to connect to the MST hub and will provide you with unparalleled connection options for Dual 4K60Hz displays. The setup is easy and simple to do provided your system supports DP1.4 specifications and DSC1.2 Compression resolutions can be limited if the source device is lower. The CSV-7220 is externally powered by a USB Type-A to Micro USB cable which comes with the product. Share
|
| Maximum Resolution Supported | 3840 x 2160 |
| Package Contents | - MST Hub DisplayPort 1.4 to DisplayPort + HDMI 4K60Hz M/F
- USB Type-A to Micro USB Power Cable 1m /3.28 ft
|
| Product color | Black |
| Product Name | MST Hub DisplayPort 1.4 to DisplayPort + HDMI 4K60Hz M/F |
| Product Type | A/V Adapter |
| UPC Alternates | 841615102204 |
