Lantronix Compact 1-Port Secure Serial (RS232/ RS422/ RS485) to IP Ethernet Device Server and Modbus Support (TCP; ASCII; RTU); Up to 256-bit AES encryption; International 110 - 240 VAC - Secure; Integrated; Plug-and-play Serial (RS232/RS422/RS85) to Ethernet Converter using Serial-over-IP technology; Modbus TCP; Modbus ASCII; Modbus RTU support; 128/192/256-bit AES encryption; Extended Temperature (-40 C to +85 C); Built-in HTTP Server; One DB-9 Serial Port; One 10/100 Mbps Fast Ethernet R
Secure; Integrated; Plug-and-play Serial (RS232/RS422/RS85) to Ethernet Converter using Serial-over-IP technology; Modbus TCP; Modbus ASCII; Modbus RTU support; 128/192/256-bit AES encryption; Extended Temperature (-40 C to +85 C); Built-in HTTP Server; One DB-9 Serial Port; One 10/100 Mbps Fast Ethernet RJ-45 Port
| Brand Name | Lantronix |
| Brand Name | Lantronix |
| Certifications & Standards | Emissions:
- FCC Part 15 Subpart B Class B
- EN55022 Class B
- EN61000-3-2 EN61000-3-3
- ICES-003 Issue 4
- AS/NZS CISPR22
Immunity:
- EN55024
- EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5
- EN61000-4-6 EN61000-4-8 EN61000-4-11
Agency Approvals:
- UL 60950-1 2nd Edition
- CAN/CSA C22.2 No. 60950-1-07 2nd Edition
- CE
- VCCI
- C-Tick
- IEC 60950-1 2005 2nd Edition
|
| Certifications & Standards | Emissions:
- FCC Part 15 Subpart B Class B
- EN55022 Class B
- EN61000-3-2 EN61000-3-3
- ICES-003 Issue 4
- AS/NZS CISPR22
Immunity:
- EN55024
- EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5
- EN61000-4-6 EN61000-4-8 EN61000-4-11
Agency Approvals:
- UL 60950-1 2nd Edition
- CAN/CSA C22.2 No. 60950-1-07 2nd Edition
- CE
- VCCI
- C-Tick
- IEC 60950-1 2005 2nd Edition
|
| Depth | 9.5" |
| Depth | 9.5" |
| Environmental Certification | RoHS |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmental Certification | WEEE |
| Environmentally Friendly | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Fast Ethernet |
| Ethernet Technology | Fast Ethernet |
| Height | 1.1" |
| Height | 1.1" |
| Input voltage | 230 V AC |
| Input voltage | 120 V AC |
| Input voltage | 230 V AC |
| Input voltage | 120 V AC |
| Limited Warranty | 5 Year |
| Limited Warranty | 5 Year |
| Manufacturer | Lantronix Inc |
| Manufacturer | Lantronix Inc |
| Manufacturer Part Number | XDT4851002IA-01-S |
| Manufacturer Part Number | XDT4851002IA-01-S |
| Manufacturer Website Address | http://www.lantronix.com |
| Manufacturer Website Address | http://www.lantronix.com |
| Marketing Information | Portable & Flexible
With an integrated Ethernet port and serial cable multiple power options including PoE and an industry-best five year warranty the xDirect-IAP device server provides a portable extremely flexible and highly affordable network connectivity solution.
Robust & Easy
With plug-and-play simplicity small form factor multiple power options and a robust device server application xDirect-IAP provides the easiest and shortest path to network connectivity 'right on the wire'. |
| Marketing Information | Portable & Flexible
With an integrated Ethernet port and serial cable multiple power options including PoE and an industry-best five year warranty the xDirect-IAP device server provides a portable extremely flexible and highly affordable network connectivity solution.
Robust & Easy
With plug-and-play simplicity small form factor multiple power options and a robust device server application xDirect-IAP provides the easiest and shortest path to network connectivity 'right on the wire'. |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Twisted Pair |
| Memory Technology | SRAM |
| Memory Technology | SRAM |
| Network Standard | 10/100Base-TX |
| Network Standard | 10/100Base-TX |
| Number of Network (RJ-45) Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Package Contents | - xDirect 485 Device Server
- 100-240 VAC International Power Supply with Regional Adapters
|
| Package Contents | - xDirect 485 Device Server
- 100-240 VAC International Power Supply with Regional Adapters
|
| Product Line | xDirect |
| Product Line | xDirect |
| Product Name | xDirect 485 Device Server |
| Product Name | xDirect 485 Device Server |
| Product Type | Device Server |
| Product Type | Device Server |
| Standard Memory | 256 KB |
| Standard Memory | 256 KB |
| UPC Alternates | 783384235694 |
| UPC Alternates | 783384235694 |
| Weight (Approximate) | 2.40 oz |
| Weight (Approximate) | 2.40 oz |
| Width | 1.3" |
| Width | 1.3" |
| Wireless LAN | No |
| Wireless LAN | No |
