Kramer TP-576 HDMI & Long-reach DGKat PoC Transceiver with RS-232 & IR - 1 Input Device - 1 Output Device - 328.08 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 1080p, 1080i - Full HD - 1920 x 1080 - Twisted Pair - Category 7
1 Input Device - 1 Output Device - 328.08 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 1080p, 1080i - Full HD - 1920 x 1080 - Twisted Pair - Category 7
| Network (RJ-45) | Yes |
| Brand Name | Kramer |
| Connectivity technology | Wired |
| Graphics Modes | Full HD |
| Manufacturer | Kramer Electronics LTD |
| Manufacturer Part Number | TP-576 |
| Manufacturer Website Address | http://www.kramerelectronics.com |
| Marketing Information | The TP-576 is a DGKat™ twisted pair line driver for HDMI bidirectional RS-232 and infrared signals. The unit receives an HDMI signal either from a local HDMI source or from a compatible twisted pair transmitter. It decodes the selected signals to the local HDMI RS-232 and IR outputs and simultaneously transmits them to a compatible twisted pair receiver.
FEATURES
- Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel HDMI); 4.95Gbps (1.65Gbps per graphic channel twisted pair).
- HDTV Compatible.
- HDCP Compliant.
- DGKat™ Signal Integration - Kramer's unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
- HDMI Support - x.v.Color™ HDMI Uncompressed Audio Channels Dolby TrueHD DTS-HD.
- 3D Pass-Through.
- -EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
- HPD Pass Thru - Passes hot plug detect signals from display to source.
- Active Input/Output LED Indicators.
- System Range - Up to 90m (295ft) at 1080i or up to 30m (98ft) at 1080p on shielded BC-DGKat524 cable. Up to 90m (295ft) at 1080i or up to 70m (230ft) at 1080p on shielded BC-DGKat623 cable. Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded BC-DGKat7a23 cable.
- Cable - For optimum range and performance use Kramer's BC-DGKat524 BC-DGKat623 and BC-DGKat7a23 cables. Note that the transmission range depends on the signal resolution graphics card and display used. The distance using non-Kramer CAT 5 CAT 6 and CAT 7 cables may not reach these ranges. Use only shielded cable where both ends of the shield are soldered to ground.
- Flexible Control - Front panel RS-232 & IR switching.
- Power Connect™ System - A single connection to the TP-576 powers the transmitter receiver and line driver units.
- Compact MegaTOOLS™ - 2 units can be rack mounted side-by-side in a 1U rack space with the optional RK-T2B universal rack adapter.
|
| Maximum Operating Distance | 328.08 ft |
| Maximum Video Resolution | 1920 x 1080 |
| Media Type Supported | Twisted Pair |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Package Contents | - TP-576 HDMI & Long-reach DGKat PoC Transceiver with RS-232 & IR
- Power Supply
- Bracket Installation Kit
|
| Product Line | MegaTOOLS |
| Product Name | TP-576 HDMI & Long?reach DGKat PoC Transceiver with RS?232 & IR |
| Product Type | Video Extender Transceiver |
| Supported video modes | 1080p |
| Supported video modes | 1080i |
| Twisted Pair Cable Standard | Category 7 |
