Cisco HyperFlex Barebone System - 2U Rack-mountable - 2 x Processor Support - Intel C621A Chip - 8 TB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 32 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - Matrox G200e 8 MB Graphic(s) - 24 2.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - Gigabit Ethernet, 10 Gigabit Ethernet - Windows Server 2019 Datacenter, Windows Server 2019 Standard Supported Operating System - Intel Optane Memory Ready
Intel C621A Chip - 8 TB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 32 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - Matrox G200e 8 MB Graphic(s) - 24 2.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - Gigabit Ethernet, 10 Gigabit Ethernet - Windows Server 2019 Datacenter, Windows Server 2019 Standard Supported Operating System - Intel Optane Memory Ready - 2 USB 3.0 Port(s) - 3 Year
| 64-bit Processing | Yes |
| Chipset | Intel C621A |
| Chipset Manufacturer | Intel |
| Chipset Model | C621A |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Maximum Memory Supported | 8 TB |
| Memory Standard | DDR4-3200/PC4-25600 |
| Number of Internal 2.5" Bays | 24 |
| Number of Processors Supported | 2 |
| Number of Total Expansion Slots | 5 |
| Optical Drive Type | No |
| Processor Supported | Xeon Silver |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Bronze |
| Additional Warranty Information | - Next business day (NBD) onsite parts replacement eight hours a day five days a week.
- 90-day software warranty on media
|
| Brand Name | Cisco |
| Controller Type | 12Gb/s SAS |
| Depth | 30" |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Form factor | Rack-mountable |
| Height | 3.4" |
| Input voltage | 120 V AC |
| Input voltage | 230 V AC |
| Limited Warranty | 3 Year |
| Manufacturer | Cisco Systems Inc |
| Manufacturer Part Number | HXAF-E-240-M6SX |
| Manufacturer Website Address | http://www.cisco.com |
| Marketing Information | Cisco HyperFlex™ Systems unlock the full potential of hyperconvergence. The systems are based on an end-to-end software-defined infrastructure combining software-defined computing in the form of Cisco Unified Computing System (Cisco UCS) servers; software-defined storage with' the powerful Cisco HX Data Platform and software-defined networking with the Cisco UCS fabric that will integrate smoothly with Cisco Application Centric Infrastructure (Cisco ACI™). Together with a single point of connectivity and hardware management these technologies deliver a preintegrated and adaptable cluster that is ready to provide a unified pool of resources to power applications as your business needs dictate. |
| Memory Technology | DDR4 SDRAM |
| Number of Total Memory Slots | 32 |
| Number of VGA Ports | 1 |
| Operating System Supported | Windows Server 2019 Datacenter |
| Operating System Supported | Windows Server 2019 Standard |
| Plug/Connector Type | C14 |
| Product Family | HyperFlex HX240C M6 |
| Product Line | HyperFlex |
| Product Name | HyperFlex HX240C M6 Barebone System |
| Product Series | HX240C M6 |
| Product Type | Barebone System |
| Rack Height | 2U |
| Weight (Approximate) | 61.73 lb |
| Width | 16.9" |
