Kramer 1:4 HDMI with RS-232 & IR to PoC Long-reach DGKat DA - 1 Input Device - 4 Output Device - 328.08 ft Range - 4 x Network (RJ-45) - 1 x HDMI In - Full HD - 1920 x 1080 - Twisted Pair - Category 7 - Rack-mountable, Desktop
1 Input Device - 4 Output Device - 328.08 ft Range - 4 x Network (RJ-45) - 1 x HDMI In - Full HD - 1920 x 1080 - Twisted Pair - Category 7 - Rack-mountable, Desktop
| Network (RJ-45) | Yes |
| Transmitter Depth | 6.42" |
| Transmitter Height | 1.72" |
| Transmitter Weight (Approximate) | 1.98 lb |
| Transmitter Width | 8.45" |
| Brand Name | Kramer |
| Connectivity technology | Wired |
| Form factor | Rack-mountable |
| Form factor | Desktop |
| Graphics Modes | Full HD |
| Limited Warranty | 7 Year |
| Manufacturer | Kramer Electronics LTD |
| Manufacturer Part Number | VM-1H4C |
| Manufacturer Website Address | http://www.kramerelectronics.com |
| Marketing Information | The VM-1H4C is a high-quality 1:4 twisted pair distribution amplifier for HDMI signal to PoC Long-reach DGKat signals. The unit receives serial commands and IR signals transparently via the RS-232 port and the TP link. It reclocks and equalizes the input signal and distributes it to four DGKat TP outputs. - Max. Data Rate - 4.95Gbps (1.65Gbps per graphic channel).
- HDTV Compatible.
- HDCP Compliant.
- DGKat™ Signal Integration - Kramer's unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables.
- I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
- HDMI Support - x.v.Color™ and uncompressed audio channels Dolby TrueHD DTS-HD.
- 3D Pass-Through.
- Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
- System Range - Up to 90m (295ft) at 1080i or up to 30m (98ft) at 1080p on shielded Kramer CAT 5 cable. Up to 90m (295ft) at 1080i or up to 50m (164ft) at 1080p on shielded Kramer CAT 6 cable. Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded Kramer CAT 7 cable.
Note: Transmission range depends on the signal resolution graphics card and display used. If using third-party shielded CAT cables both ends of the shield must be soldered to the connectors for the products to function properly. - Power Connect - The VM-1H4C provides power to the twisted pair receivers when they are within 270ft (90m) of the transmitter.
- Active Input & Output LED Indicators.
- Serial Command Handling - Receives serial commands transparently via the RS-232 port and the TP link.
- Desktop Size - Compact size. 2 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter.
Applications - Home theater presentation and multimedia applications.
- Rental and staging.
|
| Maximum Operating Distance | 328.08 ft |
| Maximum Video Resolution | 1920 x 1080 |
| Media Type Supported | Twisted Pair |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 4 |
| Package Contents | - 1:4 HDMI with RS-232 & IR to PoC Long-reach DGKat DA
- Power Supply
|
| Product Name | 1:4 HDMI with RS-232 & IR to PoC Long-reach DGKat DA |
| Product Type | Video Extender Transmitter |
| Twisted Pair Cable Standard | Category 7 |
