Black Box DKM FX KVM Extender Transmitter
| $1,837.72 |
- Dual-Head DP video with resolutions up to 1920 x 1080 on each video head
- Single-head DP video with resolutions up to 4096 x 2160
- Support for USB HID keyboards and mice
- (1) Singlemode fiber port
- Intelligent EDID management
- Compatible with Windows, Linux, Mac, and other common operating systems
- Embedded audio over the DP connector (if used with compatible endpoint)
32808.40 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 2 x USB - DisplayPort - For Windows, Sun, Linux, Unix, Mac - TAA Compliant
Product Specifications
| Transmitter Depth | 5.75" |
| Transmitter Height | 0.70" |
| Transmitter Weight (Approximate) | 9.60 oz |
| Transmitter Width | 5" |
| Additional Warranty Information | 2 Year Double Diamond™ Warranty (Standard) |
| Brand Name | Black Box |
| Connectivity technology | Wired |
| Device type | KVM Extender |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmentally Friendly | Yes |
| Graphic Mode | 4K |
| Limited Warranty | 2 Year |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | ACX2MT-DP11ATH-2C |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | The DKM FX Modular KVM Extender Interface Card extends visually lossless high-resolution DisplayPort signals over CATx cable. It also features two USB HID ports so you can easily connect your keyboards mice and other devices. You can use the extender card with the DKM FX Chassis for matrix switching or as a point-to-point KVM extender. The DKM FX Extender Card supports 4K resolutions (4096 x 2160 and 3840 x 2160) in single-head mode and up to 1920 x 1200 video in dual-head mode. Audio is directly reproduced by any connected displays with integrated speakers. The stereo signal can also be extracted and output separately. |
| Maximum Operating Distance | 32808.40 ft |
| Maximum Video Resolution | 4096 x 2160 |
| Number of Network (RJ-45) Ports | 2 |
| Package Contents |
|
| Packaged Quantity | 1 |
| Platform Supported | Unix |
| Platform Supported | Linux |
| Platform Supported | Windows |
| Platform Supported | Sun |
| Platform Supported | Mac |
| Product Name | DKM FX KVM Extender Transmitter |
| Product Series | DKM FX |
| Product Type | KVM Extender Transmitter |
