IOGEAR Cinema 4K HDBaseT-Lite Extender with HDMI Connection and POH
| $229.77 Retail $329.95 |
- Extends an HDMI® connection up to 229 ft. via one CAT5e/6/6a cable
- Achieve Cinema 4K resolutions up to 130 ft. & HD resolutions to 229 ft.
- HDBaseT Anti-Jamming resist signal interference during video transmission
- Transmit Power-over-HDBaseT (POH) to receiver via CAT5e/6/6a cable
- Daisy chain up to 3 levels to extend HDMI up to 339 ft. at 4096 x 2160 @ 60Hz resolution, or 687 ft. at 1080p
- Bi-directional RS-232 support for universal remotes, touch panels & barcode scanners
- Bi-directional IR signal
- DHCP1.4 Content protection
- Rack- Mountable
1 Input Device - 1 Output Device - 669 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
Product Specifications
| Transmitter Depth | 4" |
| Transmitter Height | 1.13" |
| Transmitter Weight (Approximate) | 1 lb |
| Transmitter Width | 5.63" |
| Brand Name | IOGEAR |
| Connectivity technology | Wired |
| Country of origin | Taiwan |
| Environmental Certification | RoHS |
| Environmental Certification | WEEE |
| Environmentally Friendly | Yes |
| Form factor | Rack-mountable |
| Graphics Modes | 4K |
| Limited Warranty | 3 Year |
| Manufacturer | IOGEAR Inc |
| Manufacturer Part Number | GVE340 |
| Manufacturer Website Address | http://www.iogear.com |
| Marketing Information | Extend 4K HDMI® Audio/Video Range With HDBaseT-Lite The Cinema 4K HDBaseT-Lite Extender with HDMI Connection and Power-over-HDBaseT (POH) offers professional-grade features reliability and video signal interference protection. Extend the range of an HDMI display up to 223 feet using a Cat 5e/6/6a cable. Achieve Cinema 4K resolutions of 4096 x 2160 @ 60Hz up to 113 feet from the source and 1080p @ 60Hz HD resolutions up to 223 feet away through a single extender. The Extender is ideal for use in home theaters conference rooms lobbies or other environments where high quality video is needed at extended ranges. Need More Distance? Daisy chain the Extender to quickly expand the distance between a display and its HDMI source. Connect up to three HDBaseT-Lite HDMI Extenders to reach a maximum range of 669 feet at 1920 x 1080 resolutions and distribute Cinema 4K quality up to 339 feet ensuring the highest quality video without signal loss or drops. Professional-Grade Features The 4K HDBaseT-Lite Extender is designed with the professional AV installer in mind. The compact all metal Extender is easily mounted in an AV rack enclosure or cabinet and features a no-slip DC jack locking mechanism and HDMI locking screw for enhanced reliability. Bi-directional RS-232 support and extended IR pass-through enable source control via a universal remote or touch panel. |
| Marketing Information | Extend 4K HDMI® Audio/Video Range With HDBaseT-Lite The Cinema 4K HDBaseT-Lite Extender with HDMI Connection and Power-over-HDBaseT (POH) offers professional-grade features reliability and video signal interference protection. Extend the range of an HDMI display up to 223 feet using a Cat 5e/6/6a cable. Achieve Cinema 4K resolutions of 4096 x 2160 @ 60Hz up to 113 feet from the source and 1080p @ 60Hz HD resolutions up to 223 feet away through a single extender. The Extender is ideal for use in home theaters conference rooms lobbies or other environments where high quality video is needed at extended ranges. Need More Distance? Daisy chain the Extender to quickly expand the distance between a display and its HDMI source. Connect up to three HDBaseT-Lite HDMI Extenders to reach a maximum range of 669 feet at 1920 x 1080 resolutions and distribute Cinema 4K quality up to 339 feet ensuring the highest quality video without signal loss or drops. Professional-Grade Features The 4K HDBaseT-Lite Extender is designed with the professional AV installer in mind. The compact all metal Extender is easily mounted in an AV rack enclosure or cabinet and features a no-slip DC jack locking mechanism and HDMI locking screw for enhanced reliability. Bi-directional RS-232 support and extended IR pass-through enable source control via a universal remote or touch panel. |
| Maximum Operating Distance | 669 ft |
| Maximum Video Resolution | 4096 x 2160 |
| Media Type Supported | Twisted Pair |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Package Contents |
|
| Product Name | Cinema 4K HDBaseT-Lite Extender with HDMI Connection and POH |
| Product Type | Video Extender Transmitter/Receiver |
| Twisted Pair Cable Standard | Category 6a |
| UPC Alternates | 881317517173 |
