Cisco Catalyst C9200CX-8P-2X2G Ethernet Switch - 8 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 240 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable, DIN Rail Mountable, Wall Mountable, Compact, Under Table
8 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 240 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable, DIN Rail Mountable, Wall Mountable, Compact, Under Table
| Number of Total Expansion Slots | 2 |
| PoE Budget | 240 W |
| Total Number of Network Ports | 8 |
| Application/Usage | Business |
| Brand Name | Cisco |
| Depth | 9.6" |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Expansion Slot Type | SFP+ |
| Features | Fanless |
| Form factor | Rack-mountable |
| Form factor | DIN Rail Mountable |
| Form factor | Compact |
| Form factor | Wall Mountable |
| Form factor | Under Table |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Height | 1.7" |
| Input voltage | 230 V AC |
| Input voltage | 120 V AC |
| Layer Supported | 3 |
| Manageable | Yes |
| Manufacturer | Cisco Systems Inc |
| Manufacturer Part Number | C9200CX-8P-2X2G-E |
| Manufacturer Website Address | http://www.cisco.com |
| Marketing Information | Introduction Extend intent-based networking everywhere Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree Catalyst 9200 Series switches offer simplicity without compromise - it is secure always on and IT simplified. As foundational building blocks for the Cisco Digital Network Architecture Catalyst 9200 Series switches help customers simplify complexity optimize IT and reduce operational costs by leveraging intelligence automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey. Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology Catalyst 9200 Series switches give you what you need now with investment protection on future innovations. With full PoE+ capability power and fan redundancy stacking bandwidth up to 160 Gbps modular uplinks Layer 3 feature support and cold patching Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center or Meraki cloud monitoring. Product overview Product highlights - Full Power over Ethernet Plus (PoE+) capability for up to 48 ports for C9200 and Power over Ethernet Plus (PoE+) capability for up to 12 ports for C9200CX. Available in fan less variants for C9200CX.
- Resiliency with Field-Replaceable Units (FRU) and redundant power supply fans and modular uplinks for C9200. C9200CX are powered by internal fixed power supply or optional power adapters when not powered by upstream 802.3bt type4 90W PSE.
- Flexible downlink options with data PoE+ or mGig
- Operational efficiency with optional backplane stacking supporting stacking bandwidth up to 160 Gbps
- UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
- Enhanced security with AES-128 MACsec encryption on C9200 and AES-256 MACsec encryption for C9200CX variants policy-based segmentation and trustworthy solutions for the whole C9200 family
- Layer 3 capabilities including OSPF EIGRP ISIS RIP and routed access
- Advanced network monitoring using Full Flexible NetFlow
|
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Network Technology | 1000Base-T |
| Network Technology | 10GBase-X |
| Networking standards | IEEE 802.1x |
| Networking standards | IEEE 802.1w |
| Networking standards | IEEE 802.3at |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3z |
| Networking standards | IEEE 802.3ad |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.1s |
| Networking standards | IEEE 802.3ab |
| Networking standards | IEEE 802.3af |
| Networking standards | IEEE 802.1p |
| Networking standards | IEEE 802.1D |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+ |
| Port/Expansion Slot Details | 2 x Gigabit Ethernet Network |
| Port/Expansion Slot Details | 2 x 10 Gigabit Ethernet Expansion Slot |
| Power source | Power Supply |
| Product color | Gray |
| Product Family | Catalyst 9200 |
| Product Line | Catalyst |
| Product Name | Catalyst C9200CX-8P-2X2G Ethernet Switch |
| Product Series | 9200 |
| Product Type | Ethernet Switch |
| Weight (Approximate) | 6.60 lb |
| Width | 10.6" |
