AXIS I8016-LVE Network Video Intercom - 5 Megapixel - CMOS - 140° Horizontal - 114° VerticalFull-duplexStainless Steel, Plastic, Zinc - Surveillance System, Access Control
5 Megapixel - CMOS - 140° Horizontal - 114° VerticalFull-duplexStainless Steel, Plastic, Zinc - Surveillance System, Access Control
| Camera Resolution | 5 Megapixel |
| Communication Mode | Full-duplex |
| Product Material | Stainless Steel |
| Product Material | Plastic |
| Product Material | Zinc |
| Vertical Viewing Angle | 114° |
| Additional Information | Minimum illumination:
- Color: 0.16 lux at 50 IRE F2.2
- B/W: 0.00 lux at 50 IRE F2.2 with IR illumination on
System on chip (SoC):
- Model: ARTPEC-7
- Memory: 2048 MB RAM 512 MB Flash
Video:
- Video compression:
- H.264 (MPEG-4 Part 10/AVC) Baseline Main and High Profiles
- H.265 (MPEG-H Part 2/HEVC) Main Profile
- Motion JPEG
- Resolution: 2592x1944 240x160
- Frame rate: Up to:30/25 fps (60/50 Hz) in all resolutions
- Video streaming:
- Multiple individually configurable streams in H.264 H.265 and Motion JPEG
- Axis Zipstream technology in H.264 and H.265
- Controllable frame rate and bandwidth
- VBR/ABR/MBR H.264/H.265
- Video streaming indicator
- Image settings: Saturation contrast brightness sharpness forensic WDR: up to 120 dB depending on scene white balance day/night threshold tone mapping exposure mode exposure zones defogging compression text and image overlay polygon privacy mask
Audio:
- Audio encoding:
- 24bit LPCM AAC-LC 8/16 kHz G.711 PCM 8 kHz G.726 ADPCM
- 8 kHz Opus 8/16 kHz
- Configurable bit rate
- Audio input/output:
- Line input line output built-in microphone (can be disabled) built-in speaker automatic gain control
- Built-in speaker
- 78 dB sound pressure at 1 kHz at 1 m distance (84 dB at 0.5 m / 20 in)
Network:
- Security: Password protection IP address filtering HTTPSa encryption IEEE 802.1x (EAP-TLS) a network access control digest authentication user access log centralized certificate management brute force delay protection signed firmware secure boot protection of cryptographic keys with FIPS 140-2 certified TPM 2.0 module Axis Edge Vault with Axis device ID
- Supported protocols: IPv4 IPv6 USGv6 ICMPv4/ICMPv6 HTTP HTTPSa HTTP/2 TLSa QoS Layer 3 DiffServ FTP SFTP CIFS/SMB SMTP mDNS (Bonjour) UPnP® SNMP v1/v2c/v3 (MIB-II) DNS/DNSv6 DDNS NTP RTSP RTP SRTP TCP UDP IGMP RTCP ICMP DHCPv4/v6 ARP SOCKS SSH NTCIP SIP LLDP Syslog Link-Local address (ZeroConf)
Storage: Support for microSD/microSDHC/microSDXC card and encryption Recording to network-attached storage (NAS)
Mounting:
- Recessed mounting using US 2-Gang- 4 inch square installation boxes or AXIS TA8201 Recessed Mount
- Wall Mounting using TI8202 Wall Mount Back Box
- Wall Mounting with conduit pipe using TI8202 Wall Mount Back Box and TI8603 Conduit Adapter
Operating conditions:
- -40 °C to 60 °C (-40 °F to 140 °F)
- Start-up temperature: -40 °C (-40 °F )
- Humidity 10-100% RH (condensing)
|
| Application/Usage | Surveillance System |
| Application/Usage | Access Control |
| Brand Name | AXIS |
| Country of origin | Poland |
| Durability | Vandal Resistant |
| Height | 4.9" |
| Horizontal Viewing Angle | 140° |
| Image Sensor Type | CMOS |
| Limited Warranty | 5 Year |
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 01995-001 |
| Manufacturer Website Address | http://www.axis.com |
| Marketing Information | AXIS I8016-LVE Network Video Intercom is a compact and highly robust network intercom designed for two-way communication video identification and remote entry control. It offers 5 MP resolution with invisible IR night vision and exceptional audio volume with echo and noise cancellation to ensure reliable 24/7 identification even in the most demanding situations. Based on open IP standards and interfaces this network intercom offers great integration possibilities and is a perfect complement to any video surveillance system. Furthermore it features multiple inputs and outputs for remote control of door locks and other equipment.
- High-quality audio and video
- Easy installation with PoE
- Open interface with IP phone integration SIP support
- Anti-ligature vandal-resistant IK10-rated
- IP66/IP69-rated with wall-mount
|
| Package Contents | - I8016-LVE Network Video Intercom
- Installation Guide
- Windows Decoder 1-user License
- Terminal Block Connector
- Allen Key (Resitorx 10)
|
| Product color | Black |
| Product Model | I8016-LVE |
| Product Name | I8016-LVE Network Video Intercom |
| Product Type | Video Door Phone Sub Station |
| Weight (Approximate) | 1.98 lb |
