Cisco Barebone System - 1U Rack-mountable - 2 x Processor Support - Intel C610 Chip - 768 GB DDR4 SDRAM DDR4-2133/PC4-17000 Maximum RAM Support - 24 Total Memory Slots - Serial ATA RAID Supported Controller - Matrox G200e 8 MB Graphic(s) - 4 3.5" Bay(s) - Processor Support (Xeon) - Gigabit Ethernet - 2 USB 3.0 Port(s) - 770 W
Intel C610 Chip - 768 GB DDR4 SDRAM DDR4-2133/PC4-17000 Maximum RAM Support - 24 Total Memory Slots - Serial ATA RAID Supported Controller - Matrox G200e 8 MB Graphic(s) - 4 3.5" Bay(s) - Processor Support (Xeon) - Gigabit Ethernet - 2 USB 3.0 Port(s) - 770 W
| 64-bit Processing | Yes |
| 64-bit Processing | Yes |
| Chipset | Intel C610 |
| Chipset | Intel C610 |
| Chipset Manufacturer | Intel |
| Chipset Manufacturer | Intel |
| Chipset Model | C610 |
| Chipset Model | C610 |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200e |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Graphics Memory Capacity | 8 MB |
| Maximum Memory Supported | 768 GB |
| Maximum Memory Supported | 768 GB |
| Maximum Power Supply Wattage | 770 W |
| Maximum Power Supply Wattage | 770 W |
| Memory Standard | DDR4-2133/PC4-17000 |
| Memory Standard | DDR4-2133/PC4-17000 |
| Number of 3.5" Bays | 4 |
| Number of 3.5" Bays | 4 |
| Number of Processors Supported | 2 |
| Number of Processors Supported | 2 |
| Processor Supported | Xeon |
| Processor Supported | Xeon |
| Brand Name | Cisco |
| Brand Name | Cisco |
| Controller Type | Serial ATA |
| Controller Type | Serial ATA |
| Depth | 31" |
| Depth | 31" |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Form factor | Rack-mountable |
| Form factor | Rack-mountable |
| Height | 1.7" |
| Height | 1.7" |
| Manufacturer | Cisco Systems Inc |
| Manufacturer | Cisco Systems Inc |
| Manufacturer Part Number | UCSC-C220-M4L |
| Manufacturer Part Number | UCSC-C220-M4L |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer Website Address | http://www.cisco.com |
| Marketing Information | Deliver Exceptional Performance for Space-Constrained Environments The Cisco UCS® C220 M4 Rack Server is the most versatile general-purpose enterprise infrastructure and application server in the industry. It is a high-density two-socket enterprise-class rack server that delivers industry-leading performance and efficiency for a wide range of enterprise workloads including virtualization collaboration and bare-metal applications. The Cisco UCS C-Series Rack Servers can be deployed as standalone servers or as part of the Cisco Unified Computing System™ (Cisco UCS) to take advantage of Cisco's standards-based unified computing innovations that help reduce customers' total cost of ownership (TCO) and increase their business agility. |
| Marketing Information | Deliver Exceptional Performance for Space-Constrained Environments The Cisco UCS® C220 M4 Rack Server is the most versatile general-purpose enterprise infrastructure and application server in the industry. It is a high-density two-socket enterprise-class rack server that delivers industry-leading performance and efficiency for a wide range of enterprise workloads including virtualization collaboration and bare-metal applications. The Cisco UCS C-Series Rack Servers can be deployed as standalone servers or as part of the Cisco Unified Computing System™ (Cisco UCS) to take advantage of Cisco's standards-based unified computing innovations that help reduce customers' total cost of ownership (TCO) and increase their business agility. |
| Memory Technology | DDR4 SDRAM |
| Memory Technology | DDR4 SDRAM |
| Number of Total Memory Slots | 24 |
| Number of Total Memory Slots | 24 |
| Operating System Supported | Windows Server 2008 R2 |
| Operating System Supported | CentOS |
| Operating System Supported | Solaris |
| Operating System Supported | Solaris |
| Operating System Supported | Oracle Enterprise Linux |
| Operating System Supported | SuSE Linux Enterprise Server |
| Operating System Supported | Windows Server 2012 |
| Operating System Supported | Red Hat Enterprise Linux |
| Operating System Supported | Windows Server 2008 R2 |
| Operating System Supported | CentOS |
| Operating System Supported | SuSE Linux Enterprise Server |
| Operating System Supported | Windows Server 2012 |
| Operating System Supported | Red Hat Enterprise Linux |
| Operating System Supported | Oracle Enterprise Linux |
| Operating System Supported | Windows Server 2012 R2 |
| Operating System Supported | Ubuntu Server |
| Operating System Supported | Windows Server 2012 R2 |
| Operating System Supported | Ubuntu Server |
| Product Name | UCS C220 M4 Barebone System |
| Product Name | UCS C220 M4 Barebone System |
| Product Series | C220 M4 |
| Product Series | C220 M4 |
| Product Type | Barebone System |
| Product Type | Barebone System |
| Rack Height | 1U |
| Rack Height | 1U |
| UPC Alternates | 882658737220 882658737244 |
| UPC Alternates | 882658737220 882658737244 |
| Weight (Approximate) | 29 lb |
| Weight (Approximate) | 29 lb |
| Width | 19" |
| Width | 19" |
