Lenovo ThinkSystem DM5000H Unified Hybrid Storage Array - 24 x HDD Supported - 0 x HDD Installed - 24 x SSD Supported - 11.52 TB Supported SSD Capacity - 12 x SSD Installed - 64 GB RAM - 2 x 12Gb/s SAS Controller - RAID Supported - 24 x Total Bays - 24 x 2.5" Bay - 8 x Total Slot(s) - 10 Gigabit Ethernet - 2 USB Port(s) - Data ONTAP 9.7 - iSCSI, NFS, CIFS/SMB, FCP, SSH, SNMP, LDAP, SSL - 4 SAS Port(s) External - 2U - Rack-mountable
24 x HDD Supported - 0 x HDD Installed - 24 x SSD Supported - 11.52 TB Supported SSD Capacity - 12 x SSD Installed - 64 GB RAM - 2 x 12Gb/s SAS Controller - RAID Supported - 24 x Total Bays - 24 x 2.5" Bay - 8 x Total Slot(s) - 10 Gigabit Ethernet - 2 USB Port(s) - Data ONTAP 9.7 - iSCSI, NFS, CIFS/SMB, FCP, SSH, SNMP, LDAP, SSL - 4 SAS Port(s) External - 2U - Rack-mountable
| Fibre Channel | Yes |
| Number of Controllers | 2 |
| Number of Hard Drives Installed | 0 |
| Number of SAS Ports (External) | 4 |
| Number of Solid State Drive Installed | 12 |
| Number of Total Expansion Slots | 8 |
| Solid State Drive Configuration | 12 x 960GB |
| SSD Cache Capacity | 1.95 TB |
| Total Solid State Drive Capacity Supported | 11.52 TB |
| Brand Name | Lenovo |
| Controller Type | 12Gb/s SAS |
| Depth | 19" |
| Environmental Certification | EU RoHS |
| Ethernet Technology | 10 Gigabit Ethernet |
| Expansion Slot Type | SFP+ |
| Form factor | Rack-mountable |
| Height | 3.3" |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7Y571031NA |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Marketing Information | Lenovo ThinkSystem DM5000H is a unified hybrid storage system that is designed to provide performance simplicity capacity security and high availability for medium enterprises. Powered by the ONTAP software ThinkSystem DM5000H delivers enterprise-class storage management capabilities with a wide choice of host connectivity options flexible drive configurations and enhanced data management features. The ThinkSystem DM5000H is a perfect fit for a wide range of enterprise workloads including data analytics artificial intelligence engineering and design enterprise applications and other storage I/O-intensive applications.
ThinkSystem DM5000H models are 2U rack-mount controller enclosures that include two controllers 64 GB RAM and 8 GB battery-backed NVRAM (32 GB RAM and 4 GB NVRAM per controller) and 24 SFF hot-swap drive bays (2U24 form factor). Controllers provide universal 1/10 GbE NAS/iSCSI or 4/8/16 Gb Fibre Channel (FC) ports or 1/10 GbE RJ-45 ports for host connectivity.
A single ThinkSystem DM5000H Storage Array scales up to 144 drives with the attachment of Lenovo ThinkSystem DM240S 2U24 SFF DM120S 2U12 and DM600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors 7.2 K rpm NL SAS hard disk drives (HDDs) and SAS solid-state drives (SSDs). |
| Number of Total Expansion Bays | 24 |
| Operating System | Data ONTAP 9.7 |
| Package Contents | - ThinkSystem DM5000H Unified Hybrid Storage Array
- Rack Mount Kit
- 2 m USB Cable (USB Type A to Micro-USB)
- Electronic Publications Flyer
- 2 x 2.8m 10A/100-250V C13 to C14 Rack Power Cables
|
| Plug/Connector Type | C13 to IEC 320-C14 |
| Product Family | ThinkSystem DM |
| Product Line | ThinkSystem |
| Product Model | DM5000H |
| Product Name | ThinkSystem DM5000H Unified Hybrid Storage Array |
| Product Series | DM |
| Product Type | SAN/NAS Storage System |
| Protocols | FCP |
| Protocols | NFS |
| Protocols | CIFS/SMB |
| Protocols | SSL |
| Protocols | SNMP |
| Protocols | iSCSI |
| Protocols | SSH |
| Protocols | LDAP |
| Rack Height | 2U |
| Standard Memory | 64 GB |
| Weight (Approximate) | 60.80 lb |
| Width | 17.6" |
