SMC Networks EZ Switch 10/100/1000 Mbps 24-Port Unmanaged Gigabit Ethernet Switch
| $194.78 Retail $366.99 |
- Features 24 networking ports to establish large network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
- Built-in power supply to ensure all components are being supplied with accurate voltage
24 Ports - 10/100/1000Base-T - 2 Layer Supported - Desktop, Rack-mountable - 2 Year Limited Warranty
Product Specifications
| Brand Name | SMC Networks |
| Certifications & Standards |
|
| Depth | 7.1" |
| Ethernet Technology | Gigabit Ethernet |
| Form factor | Desktop |
| Form factor | Rack-mountable |
| Height | 1.7" |
| Input voltage | 220 V AC |
| Input voltage | 110 V AC |
| Layer Supported | 2 |
| Limited Warranty | 2 Year |
| Manageable | No |
| Manufacturer | Edge-Core Networks Corporation |
| Manufacturer Part Number | SMCGS2401 NA |
| Manufacturer Website Address | http://www.edge-core.com |
| Marketing Information | SMC introduces the latest Gigabit switch to the EZ Switch 10/100/1000 family - the SMCGS2401. This switch provides Gigabit Ethernet connectivity from the network backbone all the way to the edge and to individual desktops. With up to 10 times the speed of 100 Mbps networks this switch reduces transfer times of large data files and boosts bandwidth-intensive applications thereby significantly enhancing overall network performance. Jumbo frame support enables more efficient data transfers with data packets up to 9 KBytes in size. The SMC EZ Switch is easy to install and an ideal solution for network migration as it is equipped with 10/100/1000 Mbps Auto MDI/MDIX ports. Not only is each port triple-speed all ports can be either connected to a workstation or another switch without the need for cross-over cables. Providing non-blocking wire-speed throughput the switch can handle the growing performance needs of emerging bandwidth-hungry applications. |
| Media Type Supported | Twisted Pair |
| Network Technology | 10/100/1000Base-T |
| Number of Network (RJ-45) Ports | 24 |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network |
| Power source | Power Supply |
| Product Line | EZ Switch |
| Product Model | SMCGS2401 |
| Product Name | EZ Switch 10/100/1000 Mbps 24-Port Unmanaged Gigabit Ethernet Switch |
| Product Type | Ethernet Switch |
| UPC Alternates | 662698600797 |
| Weight (Approximate) | 3.63 lb |
| Width | 11.6" |
