Kramer OPS-Compatible HDMI Receiver with Ethernet & RS-232 over Extended-Reach HDBaseT - 1 Output Device - 590.55 ft Range - 2 x Network (RJ-45) - 1 x HDMI Out - Full HD - 1920 x 1080 - Twisted Pair
1 Output Device - 590.55 ft Range - 2 x Network (RJ-45) - 1 x HDMI Out - Full HD - 1920 x 1080 - Twisted Pair
| Network (RJ-45) | Yes |
| Receiver Depth | 4.69" |
| Receiver Height | 1.18" |
| Receiver Weight (Approximate) | 10.58 oz |
| Receiver Width | 7.09" |
| Brand Name | Kramer |
| Connectivity technology | Wired |
| Graphics Modes | Full HD |
| Limited Warranty | 7 Year |
| Manufacturer | Kramer Electronics LTD |
| Manufacturer Part Number | OPS-1 |
| Manufacturer Website Address | http://www.kramerelectronics.com |
| Marketing Information | OPS-1 is an OPS-compatible HDBaseT receiver for displays and AV devices with standard Intel OPS-compatible card slots. It is a high-performance extended-reach HDBaseT 1.0 receiver for full HD HDMI Ethernet and RS-232 signals over twisted pair. It extends video signals to up to 100m (330ft) over CAT copper cables at up to 1080p@60Hz video resolution. - High Performance Standard Extender - Professional HDBaseT extender for providing extended-reach signals over twisted-pair copper infrastructures. OPS-1 is a standard extender that can be directly plugged to HDBaseT-compliant OPS-slot of market-available displays and AV products. For optimum extension reach and performance use recommended Kramer cables.
- HDMI Signal Extension - HDMI 1.4 and HDCP 1.4 compliant. Supports deep color x.v.Color™ lip sync HDMI uncompressed audio channels Dolby TrueHD DTS-HD 2K and 3D. EDID and CEC signals are passed through from the source to the display.
- Multi-channel HDMI Audio Extension - Up to 8 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.
- Ethernet Extension - Ethernet interface data flows in both directions allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.
- Bidirectional RS-232 Extension - Serial interface data flows in both directions allowing data transmission and device control.
- Cost-effective Maintenance - Status LED indicator to facilitate easy local maintenance and troubleshooting.
- Easy and Elegant Installation - Directly plugged into OPS-compatible AV devices drawing power from the device. Provides single cable connectivity for all HDBaseT signals.
Applications - Long-distance AV and LAN signal extension for multi-room large dividable auditoriums and lecture hall connectivity
|
| Maximum Operating Distance | 590.55 ft |
| Maximum Video Resolution | 1920 x 1080 |
| Media Type Supported | Twisted Pair |
| Number of HDMI Outputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Product Name | OPS-Compatible HDMI Receiver with Ethernet & RS-232 over Extended-Reach HDBaseT |
| Product Type | Video Extender Receiver |
